Howo Truck Mounted Crane 6x4 400hp 5 Ton SQ5SK2Q Telescopic Crane
Howo Truck Mounted Crane 6x4 400hp 5 Ton SQ5SK2Q Telescopic Crane
Specifications
Brand Name :
SINOTRUK
Model Number :
ZZ1257V4647B1
Certification :
ISO/CCC
Place of Origin :
China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
1000 units/month
Delivery Time :
15-25 days
Packaging Details :
nude package
Chassis Model :
ZZ1257V4647B1
Crane Model :
SQ5SK2Q
Engine :
WP12.400E201
Crane capacity :
5 ton
Front axle :
VGD95
Drive axle :
HC16
Crane type :
telescopic boom crane
Optional fuel tank :
400L
Description

WEICHAI Engine Howo Truck Mounted Crane 6x4 400hp 5 Ton SQ5SK2Q Cargo Box

Chassis Model: ZZ1257V4647B1.
Brand: Howo.

Application: Truck.
ABS control system: without ABS.
Bumper: high bumper (all metal).
Gearbox: HW19710 gearbox + HW70 flange type power take-off.
Frame: double-layer frame (8+8/300).
Engine: WP12.400E201 engine.
Cab: HW76 new front cab.
Exhaust system: standard version exhaust system.
Front axle: VGD95 front axle (drum);
Drive axle: HC16 double rear axle (drum).
Optional fuel tank: 400L fuel tank.
Tires: 12.00R20 tires.
Suspension: front and rear reinforced multi-leaf springs (10/12).
With intercooler protection device; with start-stop switch under the car; with reversing buzzer; with rear tow hook.
With fire extinguisher; cab double overhead warning lights.

Crane: SQ5SK2Q 5-ton straight arm crane.
Carriage: 7100*2300*600, bottom 3mm sides 1.5mm, corrugated board.

Specification Of HOWO SQ5SK2Q 5 Ton Truck Mounted Crane:

Items Description Parameter
Model ZZ1257V4647B1

Chassis

 Brand SINOTRUK
Dimension 11184*2496*3048 mm
Curb Weight 11700kg

Cabin

 Cab 2 seats & 1 sleeper with A/C
Air Conditioner with A/C

Chassis

 Drive Type 6x4, LHD (RHD for option)
Fuel Type Diesel
Engine WP12.400E201, Euro 2 emission
Power 294kW
Displacement 11.596L
Emission Standard Euro II
Brake Air Brake
Wheelbase/No.of axle 4600mm
Tyre 12.00R20, 10pcs + 1 spare tire
Max Speed 102km/h
Painting Automative metallic paint
Cargo box Size 7100*2300*600mm
Thickness bottom 3mm, side 1.5mm

Crane

 Model SQ5SK2Q
Max Lifting Capacity 5,000kg
Max lifting moment 12.5T.M
Recommend power 18KW
Recommend hydraulic flow 32L/min
Rated hydraulic pressure 20mpa
Oil tank capaicty 90L
Rotation Angle 360 degree
Installation Space 900mm
Crane Weight 2120kg
