ADR 40/60ton Side Wall Semi Trailer 1310mm Axlebase For Cargo Truck
ADR 40/60ton Side Wall Semi Trailer 1310mm Axlebase For Cargo Truck
ADR 40/60ton Side Wall Semi Trailer 1310mm Axlebase For Cargo Truck
ADR 40/60ton Side Wall Semi Trailer 1310mm Axlebase For Cargo Truck
ADR 40/60ton Side Wall Semi Trailer 1310mm Axlebase For Cargo Truck
ADR 40/60ton Side Wall Semi Trailer 1310mm Axlebase For Cargo Truck
ADR 40/60ton Side Wall Semi Trailer 1310mm Axlebase For Cargo Truck
ADR 40/60ton Side Wall Semi Trailer 1310mm Axlebase For Cargo Truck
Specifications
Brand Name :
Harvest
Model Number :
Harvest
Certification :
CE/DOT/ADR
Place of Origin :
China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
1000 units/month
Delivery Time :
15 days
Packaging Details :
nude package
Size: :
13000mm*2590mm*2400mm
Max Payload: :
60 Tons
Axle: :
FUWA brand
Tire: :
12.00R20
King pin: :
2"(50mm)or3.5"(90mm) JOST
Color: :
Custom's Requirement
Axlebase: :
1310mm
Material: :
steel
Description

Payload 40/60 Ton Side Wall Semi-Trailer For Containers/Cargo Transport Pallet truck

We provide semi-trailers of various tonnages and models, and can also be customized according to customer requirements. Our semi-trailers are exported all over the world. Quality first, win-win cooperation.

Side Wall Semi-Trailer Technical Parameters

Side Wall Semi-Trailer Product Description
External Dimension 13000mm×2590mm×2400mm
Main Beam Heavy duty and extra durability I beam; opting for high tensile steel Q345,welding by automatic submerged-arc processes; Top flange 14mm,width 140mm;middle flange 8mm; bottom flange 16mm,width 140mm
Side Beam 16# channel steel(U-steel)
Floor Checkered plate ,thickness 5mm,Q235 material
Side wall 800mm,by your need
Axle Number 3 Brand FUWA Capacity 13T
Suspension Mechanical suspension
Leaf Spring 90mm×13mm×10
Tire 12.00R20
Wheel rim 8.5-22.5 steel wheel rim optional upon choice
King pin 2’/3.5’ bolt-in type
Landing gear Holland, two-speed ,manual operating, heavy duty landing gear
Twist lock 4/8/12,By your need
Braking System WABCO RE6 relay valve; T30/30 spring brake chamber ;40L air tanks
Electrical System Voltage 24V, receptacle 7 ways (7 wire hamess); LED light, one set 6-core standard cable.
Painting Complete chassis sand blasting to clean rust ,1 coat of anticorrosive prime,2 coats of final paint
Accessories

One standard tool box

ADR 40/60ton Side Wall Semi Trailer 1310mm Axlebase For Cargo TruckADR 40/60ton Side Wall Semi Trailer 1310mm Axlebase For Cargo Truck
