Specifications
Brand Name :
Sinotruk
Model Number :
ZZ1251N464GE1
Certification :
ISO CCC
Place of Origin :
Jinan China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000 units per month
Delivery Time :
Within 20 work days after receive order
Packaging Details :
Nude, Polished with wax before shipping on board
Truck name :
22000L Water Sprinkler Truck
Dimensions :
9650×2500×3000(mm)
Total weight :
25000(Kg)
Curb weight :
11370(Kg)
Engine :
WD615.69, 336hp
Water tank :
6500×2300×1500mm, tank volume 22m3, carbon steel Q345, body-4mm, seal-5mm
Description

22000L Water Sprinkler Truck 6x4 Liquid Tanker Truck 4300mm Wheelbase

Features of 22000L Water Sprinkler Truck

The tank body is made of high-quality WISCO carbon steel sheet (stainless steel or glass steel can be selected), and it is formed by a large-scale plate bending machine at one time. The joint between the head and the tank body adopts an advanced arc welding process. Platform guardrails are reinforced with gas shielded welding.

Equipped with high-power sprinkler pump (pump can self-suction and suction discharge), front and rear sprinkler, side spray, high side shower, rear working platform, green sprinkler cannon on the platform, the sprinkler can be adjusted into a column, the range of ≥28m; also It can be adjusted into a mist shape with a range of ≥15m.

According to user requirements, it can be installed with medicine tray, medicine pump, anti-corrosion and anti-rust in the tank, multi-directional water inlet and outlet joints, solenoid valve, pneumatic valve, etc.

Technical specification of 22000L Water Sprinkler Truck

Sinotruk HOWO 6x4 water sprinkler truck ZZ1251N464GE1
product name HOWO 6x4 water tank truck Dimensions 9650×2500×3000(mm)
Total weight 25000(Kg) Approach/departure angle 13/11(°)
Rated weight 13500,13435(Kg) Front overhang 1320/2180,1320/2490,1320/3000(mm)
Curb weight 11370(Kg) Maximum speed 101(km/h)
Engine SINOTRUK Displacement (ml) Power(kw)
WD615.69 SINOTRUK 9726 228
Number of axes 3 Front track: 2035(mm)
Wheelbase 4350+1350 Rear track: 1850/1850(mm)
Number of tires 10 Tire specifications: 11.00-20,11.00R20 18PR/11.00R20 16PR,12R22.5 18PR/12R22.5 16PR,295/80R22.5 18PR/295/80R22.5 16PR
Fuel type Diesel Number of springs: 3/5,3/10,11/10,11/12,3/-,11/-,3/4
Axle load 7000/18000(double axles) Number of passengers in the cab: 2,3
Water tank 6500×2300×1500mm, tank volume 22m3, carbon steel Q345, body-4mm, seal-5mm
336hp 22000L Wheelbase 4300mm 6x4 Liquid Tanker Truck
336hp 22000L Wheelbase 4300mm 6x4 Liquid Tanker Truck
336hp 22000L Wheelbase 4300mm 6x4 Liquid Tanker Truck
336hp 22000L Wheelbase 4300mm 6x4 Liquid Tanker Truck
336hp 22000L Wheelbase 4300mm 6x4 Liquid Tanker Truck

Our Services

1. Reply your inquiry in 12 working hours;

2. Experienced staffs answer all your questions;

3. Customer’s design is available for certain products(OEM);

4. Spare parts for all types of engine machinery with reasonable price;

5. Different kinds of semi trailer and trucks can be provided with competitive price.

We Will Check Again Before delivery or Shipping. We must guarantee our trucks or trailers perfect and pictures will taken and sent to our customers.
