Yellow Color Construction Bulldozer Heavy Equipment TY320T 160hp 180hp
Yellow Color Construction Bulldozer Heavy Equipment TY320T 160hp 180hp
Yellow Color Construction Bulldozer Heavy Equipment TY320T 160hp 180hp
Yellow Color Construction Bulldozer Heavy Equipment TY320T 160hp 180hp
Yellow Color Construction Bulldozer Heavy Equipment TY320T 160hp 180hp
Yellow Color Construction Bulldozer Heavy Equipment TY320T 160hp 180hp
Specifications
Brand Name :
LTMG
Model Number :
TY320T
Certification :
ISO CCC
Place of Origin :
China
MOQ :
One set
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
200 Unit/Units per Month
Delivery Time :
30-35 work days
Packaging Details :
In nude
Max.drop below ground :
545mm
Machine Weight :
17900kg
Max.Lift :
1100mm
Fuel Tank Capacity :
320L
Blade Capacity :
4-8.6cbm
Weight Of Blade :
2560
Description

Yellow Color Construction Bulldozer Heavy Equipment TY320T 160hp 180hp

Construction Bulldozer TY320T 160hp 180hp Bulldozer In Yellow Color

The specification of Construction Bulldozer TY320T

The specification of 160hp bulldozer
SPECIFICATION
Specification/Blade type Straight-tilt Angle U-Blade
Operating Weight Kg 17400 17700 17900
Min.Turning Radius M 3.2 3.2 3.2
Ground Pressure MPa 0.069 0.07 0.071
Track Gauge MM 1880 1880 1880
Max. Pulling Force KN 142 142 142
Grade Ability ° 30 30 30
TRAVEL SPEED
1st 2nd 3rd
Forward (km) 0～3.8 0～6.6 0～10.6
Reverse (km) 0～10.6 0～8.5 0～13.6
ENGINE
Model & Type Weichai WD10G178E25
6-cylinder, in-line, vertical. water-cooled, 4-stroke-cycle, turbo-charged, over valve directs injection
Rated Revolution (rpm) 1850
Flywheel Horsepower (HP) 160
Cylinder Number-BoreX Stroke (mm) 6-126X 130
Piston Displacement (L) 9.73
Min. Fuel Consumption (g/kW.h) 223
Max.Torque (Nm/rpm) 830/1100
Starting Motor V*KW 24*7.5
POWER TRANSMISSION SYSTEM
Torque Converte 3-element,1-stage,1-phase
Transmission Planetary gearing, hand-manipulated, hydraulic shift, forced lubrication,3 forward and 3 reverse speeds
Bevel Gear Spiral bevel gear, splash lubrication, single-stage speed reduction
Steering Clutch Wet, multi-disc, spring loaded, hydraulically separated, hydraulic control
Steering Brake Wet, band type, pedal hydraulic booster, with parking brakes
Final Drive Double reduction of spur gear, splash lubrication
HYDRAULIC SYSTEM
Pump Type Gear pump 07441-67503
Working Pressure (MPa) 13.4
System Discharge (L/min) 250
Working Cylinder type Double-acting piston type
Working Cylinder Lift Number-BoreXRodXStroke (mm) 2-110X65X1026
Working Cylinder Tilt BoreXRodXStroke (mm) 160X70X140
UNDERCARRIAGE SYSTEM
Type Swing type of sprayed beam, suspended structure of equalizer bar
Carrier Rollers 2(each side)
Track Rollers 6/each side (4-single flange, 2-double flange)
Track Type Sealed, assembled single- grouser
Number Of Track Shoes 37(each side)
Width Of Track Shoes (mm) 510
Pitch (mm) 203.2
Length Of Track 0n Ground (mm) 2430
WORK EQUIPMENT
Specification/Blade type Straight-tilt Angle Angle
Blade Capacity (m3) 4.5 4.3 8.6
Blade Width X Height (mm) 3416×1145 3970×1037 4064×1386
Max.Lift (mm) 1110 1095 1110
Max.Depth (mm) 530 545 530
Max.tilt Adjustment (mm) ≥860 ≥400 ≥400
Pitch Adjustment ( ° ) 55 55 55
Capability (m3/H) 247 247 260
Weight Of Blade (kg) 2350 2450 2560
COOLANT AND LUBRICANT CAPACITY
Fuel Tank Capacity L 320
Hydraulic Tank Capacity L 108
Engine oil Capacity L 45
Torque Converter ,Transmission, Bevel Gear., Steering Clutch Capacity L 122
Final Drive Capacity (L) 33(each side)
RIPPER(OPTIONAL)
3-Shank Ripper:
Max.Digging Depth (mm) 572
Max.Lift (mm) 702
Shank Of Distance (mm) 950
Weight (kg) 1700

Advantage of Construction Bulldozer TY320T

1. The Weichai electronic control, direct injection, turbocharged engine equipped features high torque reserve coefficient, excellent energy-conservation and environment-friendliness, and strong power.

2. The split transmission and torque converter system, single-turbine three-element torque converter, and AMT full-automatic electronic control transmission feature simple structure and higher reliability.


3. The electronic control joysticks feature convenient and flexible operations and incorporate the blade floating function.


4. The full-hydraulic maintenance-free wet drive axle features fast response, stable braking, and high safety and reliability.

OUR SERVICE

Warranty: We supply one year warranty for all the machines we exported, during the warranty, if there is problem caused by machine quality without improper operation, we will supply the replace genuine parts by DHL to clients freely to keep the machine in high efficiency work.

Spare Parts: We have 7years experience on machine and spare parts supplying, we are efforts to supply Genuine brand spare parts with good prices, quick response and professional service.

Product Show

Yellow Color Construction Bulldozer Heavy Equipment TY320T 160hp 180hpYellow Color Construction Bulldozer Heavy Equipment TY320T 160hp 180hpYellow Color Construction Bulldozer Heavy Equipment TY320T 160hp 180hp
