High Strength Mining Dump Truck Heavy Duty 10 Wheels ZZ3257N4147W 35t
High Strength Mining Dump Truck Heavy Duty 10 Wheels ZZ3257N4147W 35t
High Strength Mining Dump Truck Heavy Duty 10 Wheels ZZ3257N4147W 35t
High Strength Mining Dump Truck Heavy Duty 10 Wheels ZZ3257N4147W 35t
High Strength Mining Dump Truck Heavy Duty 10 Wheels ZZ3257N4147W 35t
High Strength Mining Dump Truck Heavy Duty 10 Wheels ZZ3257N4147W 35t
High Strength Mining Dump Truck Heavy Duty 10 Wheels ZZ3257N4147W 35t
High Strength Mining Dump Truck Heavy Duty 10 Wheels ZZ3257N4147W 35t
Specifications
Brand Name :
Howo
Model Number :
ZZ3257N4147W
Certification :
ISO CCC
Place of Origin :
Jinan China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000 units per month
Delivery Time :
Within 30 work days after receive order
Packaging Details :
Nude, Polished with wax before shipping
Product name :
Sinotruk Howo 10 Wheels Heavy Duty Mining Dump Truck
Cab :
HOWO76 cab, one sleepers, with air-condition
Dimension(L x W x H)(mm) :
8145x2496x3370
Cargo body size (Lx W x H) (mm) :
5400x2300x1300 20 m3
Cargo box thickness :
bottom:8mm, side:6mm
Engine :
WD615.69, 336hp
Description

High Strength Mining Dump Truck Heavy Duty 10 Wheels ZZ3257N4147W 35t

Sinotruk Howo 10 Wheels Heavy Duty Mining Dump Truck Model ZZ3257N4147W 35t Tipper Truck

Features of Sinotruk Howo 10 Wheels Heavy Duty Mining Dump Truck Model ZZ3257N4147W 35t Tipper Truck

1. Dump truck cargo box adopts high-strength and high-quality carbon steel, which has good wear resistance and long service life.

2. Engine adopts Steyr technology, strong power and good engine performance

3. Cab is spacious and bright, the driving experience is comfortable, and the field of vision is good

4. Chassis Frame has high strength and reasonable design.

5. Good quality and famous brand tires.

Technical specification of Sinotruk Howo 10 Wheels Heavy Duty Mining Dump Truck Model ZZ3257N4147W 35t Tipper Truck

Model ZZ3257N4147W
Cab HOWO76 cab, one sleepers, with air-condition
Dimension(L x W x H)(mm) 8145x2496x3370
Cargo body size (Lx W x H) (mm) 5400x2300x1300 20 m3
bottom:8mm, side:6mm
Lifting type Middle Lift
Approach/Departure angle(°) 19/26
Overhang(front/rear) (mm) 1500/1739
Wheel base (mm) 3825+1350
Max speed(km/h) 75
Curb weight(kg) 12290
Loading Weight(kg) 30000
Fuel tanker capacity(L) 300
Fuel consumption(L/km) 20-40 L/100 km
Clutch Single-plate dry clutch Φ430mm
Fuel type Diesel
Horse Power 336HP
Emission EURO II
Engine WD615.69, water-cooled,four strokes,6 cylinders in line with water cooling,
turbocharged and intercooling, directly injection
Transmission HW19710,10 forwards and 2 reverse
Service brake Dual circuit compressed air brake
Parking brake Spring energy, compressed air operating on rear wheels
Model 8118 hydraulic steering with power assistance
Front axle HF9 , Steering with double T-cross section beam
Rear axle HC16, Pressed axle housing, central double reduction with differential locks between axles and wheels
Tire 12.00R20

High Strength Mining Dump Truck Heavy Duty 10 Wheels ZZ3257N4147W 35t

High Strength Mining Dump Truck Heavy Duty 10 Wheels ZZ3257N4147W 35t

High Strength Mining Dump Truck Heavy Duty 10 Wheels ZZ3257N4147W 35t

Our Service

Pre-Sales Service

* Inquiry and consulting support.
* Sample testing support.
* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.

FAQ:

Which countries do you export to?
Asia: India, Philippines, Thailand, Burma, Vietnam, Bangladesh, Kazakhstan, Turkmenistan, etc. Middle East: Saudi Arabia, Iran, UAE, Jordan, Oman, Syria, Pakistan, Qatar, etc. Europe: Russia, Ukraine, Belarus, Bulgaria, etc. Africa: South Africa, Kenya, Congo, Ethiopia, Nigeria, Ghana, Algeria, Senegal, Tunisia, etc. South America: Brazil, Peru, Chile, Cuba, Venezuela, Mexico, etc. Oceania: Papua New Guinea, Australia, etc.

What is the proportion of your products exported?
75% of our products are exported to all over the world.

What is the payment term?
Payment term is negotiable and there will be favorable payment terms for long-term customers. TT, L/C, D/P, depending on the cooperation time, country and contract value.

What kind of logistic service do you supply?
A. Transportation: railway transportation, international through transport, including (international railway through transportation, Sea-rail intermodal through transportation, sea-land multimodal transportation. Means of transport : Container, LCL, FRC, ro-ro, bulk cargo, train carriage, truck, air plane.
B. Term: FOB,CIF, DAP, to door service, etc.

What spare parts can you supply?
All kinds of spare parts of XCMG, SHANTUI, ZOOMLION, SINOTRUCK, SHACMAN, LIUGONG, SANY, SDLG, LONKING, XGMA, CUMMINS ENGINE, ZF GEAR BOX, etc.
