Sewage Suction Vehicle 12000 Liters 15m3 Vacuum Sewer Suction Truck 290hp

Sinotruk HOWO 4x2 12000 Liters 15m3 Vacuum Sewage Suction Truck Special Purpose Tank Truck 290hp

Introduction of the equipment of Sinotruk HOWO 4x2 12000 Liters Vacuum Sewage Suction Truck

Suction truck, the volume of the tank body is 12-15 cubic meters,

Tank body is made of high quality Q235 carbon steel plate of WISCO

Shape is round, the head is thick steel plate,

Tank is treated with anti-rust paint, and the connection between the pipeline and the tank body can be Detachable type,

With unblocking port for easy unblocking; equipped with a full set of Hangzhou Weilong vacuum system: high-power vacuum pump, oil and gas separator, water and gas separator, stainless steel anti-overflow valve, four-way valve, etc. ),

The back of the tank body with a ball valve self-flow, front view of the faecal pipe, rear view of the septic window; the tank can be lifted hydraulically,

The head can be opened hydraulically, mechanically locked. With hand-washing box. Others are standard.

Features of Sinotruk HOWO 4x2 12000 Liters Vacuum Sewage Suction Truck Chassis: The chassis adopts Sinotruk high-quality original chassis at home and abroad, with optional wheelbase, Euro III emission engine, and nationwide warranty.

The tank body undergoes a strict welding process, a large-scale plate rolling machine is formed at one time, the reinforced head is fully welded, rust-proofed, and sprayed with multiple top coats. The patterns and words can be sprayed according to customer requirements;

Use famous brand high-power vacuum pump, with good lubrication, reliable work, low fuel consumption during pumping, and good pumping capacity, so it ensures the reliable use of the pumping system;

Powerful, with three functions of vacuum suction, pressure discharge and self-flow discharge, the pipeline design is novel and advanced, easy to install and maintain, and greatly simplified operation;

The key components such as control valves, oil cylinders, and connecting pipes of the famous brand hydraulic system are used, with advanced structure, reliable performance, simple operation and convenient maintenance;

​Install the controller of anti-liquid overflow device. When the liquid reaches the rated range, the controller float immediately closes the vacuum pipeline to prevent liquid from overflowing into the vacuum pump and affecting the normal operation of the vacuum pump;

There is a glass liquid level inspection tube in the front of the tank, and an inspection window at the rear, which clearly displays the height of the liquid level inside the tank. Optionally, a liquid level alarm device can be installed to obtain the liquid level in time.

Technical specification of Sinotruk HOWO 4x2 12000 Liters Vacuum Sewage Suction Truck

After-sale services:

1. more than 200 professional worker to supply high quality products;

2. Own engineer to design according to your request;

3. QC team to control the all production line;

4. Sales team to follow on all details for you;

5. CNCA+CCC+after sales service+quanlity warranty;

FAQ:

1.Q: How about the warranty?

A: One year

2.Q: Do you have ISO certificate ?

A: Yes , we have,pls contact us to get our certifications.

3.Q: How about the delivery time?

A: It depends on the style of truck ,normally around 30 working days

4. Q: How about shipping ?

A: Big size trucks always shipping by RORO or Bulk ship or flat bed container or open top container , small type can shipping by container ,Pls contact us to get a shipping quotation .

5. Q: How do you control the quality of product?

A: our workers are well trained. Our very product under goes a scrutinizing inspection process.

6. Q: How about your product After-sales service system?

A: Our main export country have accepted after-sales service,some of country used the third department service.

7. Q: Do you accept Custom orders? What’s is your MOQ order?

A: Yes, we do, our MOQ is 1 set.

8. Q: What’s the payment terms?

A: By T/T or L/C at sight ,Western Union
