Isuzu Aerial Work Platform Truck Max Lifting Height 16 Meter Forward 620mm

Isuzu Aerial Work Truck, Aerial Work platform, Max.lifting height 16m, forward 620mm, Engine 63kw, Euro III/IV, 3 person.

Specification:

Special function description of aerial work truck:

We produce Dongfeng (8-24m) aerial work vehicle, Jiangling (14-16m) aerial work vehicle, Qingling (14-16m) aerial work vehicle, JAC (18m) aerial work vehicle, Isuzu (16m) High-altitude operation vehicle, Futian (14m) aerial work vehicle, Dongfeng Tianjin (20m 22m) aerial work vehicle, etc. Two-arm boom lift truck, three-arm boom lift truck, hydraulic lift platform truck (5m-10m)

Function overview: The high-altitude operation vehicle uses a directional valve and a hydraulic oil cylinder, which is balanced in direction, flexible and convenient to operate, and the legs and working arms are interlocked to prevent misoperation.

Four hydraulic legs are installed with the vehicle to ensure the stability and safety of the entire vehicle during operation.

High-altitude operation truck with 1 ton hook,

The aerial work vehicle can be operated up and down, 360-degree rotation, and a hand throttle is installed.

If you have special requirements for aerial work vehicles, please call us, we can design and modify for customers' orders. Electric control system can be added.

All the main booms and booms of our aerial work vehicles are made of high-strength steel plates and are formed by bending. Carbon dioxide automatic protective welding allows only two welds, with few welds, small deformation, high accuracy and strength, and has been tested by ultrasonic welds.

The machining, welding, and assembly of all shaped products are completed on tooling and fixtures, thereby ensuring quality and interchangeability.

All of the high-altitude trucks produced by our company use carbon dioxide protection welding and argon arc welding. Weld length is more than 300mm, and automatic seam is used to ensure that the strength of the weld is not lower than the strength of the base metal, and make the surface of the weld smooth and beautiful .

The high-altitude operation truck produced by our company adopts the original chassis and flat head, which can accommodate more operators. Stable and reliable performance, mainly used for electrical line maintenance, aerial work cleaning, tree pruning and other aerial work.
