Specifications
Brand Name :
Sinotruk
Model Number :
BCZH-15G
Certification :
ISO CCC
Place of Origin :
Jinan China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000 units per month
Delivery Time :
Within 30-35 work days after receive order
Packaging Details :
Nude, Polished with wax before shipping on board
Product name :
Sinotruk Howo 8x4 15t Heavy Anfo Truck BCZH-15G
Chassis :
Sinotruk Howo 8x4
Engine :
336hp, 371hp
Dimension of the machine and equipment :
11360×2500×3750mm
Mixing charger device of material :
Stainless steel
Amount of explosives :
15000kg
Emulsion/ANFO ratio :
70/30 %
Borehole charging depth :
20-30m
Borehole charging speed :
Wed Borehole: 200--280kg/min Dry Borehole: 300--450kg/min
Storage tank for produced emulsion /equipment/ :
8.4m3/10500kg
Porous ammonia container /equipment :
Min-3.4m3/4500kg
Water tank volume :
0.4m3
Description

Sinotruk Howo 8x4 15t Heavy Anfo Truck BCZH-15G On-Site Mixed Heavy Ammonium Explosive Truck

Introduction of Sinotruk Howo 8x4 15t Heavy Anfo Truck BCZH-15G On-Site Mixed Heavy Ammonium Explosive Truck

Sinotruk Howo 8x4 15t Heavy Anfo Truck BCZH-15G integrates the transportation, mixing and filling of raw materials. It can mix pure emulsified explosives, heavy ammonium explosives and ammonium explosives of various proportions on site. The vehicle is a multi-function vehicle with good silo configuration performance. It can mix 15t of emulsified explosives or 15t of ammonium explosives or 15t of heavy ammonium explosives on site. The advanced computer operating system can accurately load two A variety of explosives with different formulas have a safety guarantee system for over-temperature, over-pressure, material shutdown alarm and shutdown, which is safe and reliable.

Technical specification of Sinotruk Howo 8x4 15t Heavy Anfo Truck BCZH-15G On-Site Mixed Heavy Ammonium Explosive Truck

Chassis
Brand&Model SINOTRUK HOWO ZZ1317N3867A

Engine

 Model WD615.47
Manufacture Sinotruk
Type

Diesel,

water-cooled, four strokes, 6 cylinders, in line with water cooling, turbo charged, And inter-cooling & direct injection.
Engine capacity 371hp
Emission standard Euro II
Drive wheel formulation 8x4
Wheelbase 1800+3800+1350mm
Cabin HW70, no sleeper
Transmission HW19710 transmission + HW70 flange type power take-off
Front axle MAN VPD060QB front axle (disk)
Loading: 6000kg
Chimney system Smoke evacuation (with fire lid)
Tires 12.00R20 /steel tires/, 12+1 pcs
Fire extinguisher one pieces for machine, two pieces for equipment
Warnings Hazardous freight warnings according to Mongolian law and regularity must be sticked /4 sides of the machine /
Amber light

On the cabin-1 pieces

Equipment -1 pieces
Other directions
  • PTO option: /front and bottom protection/
  • Speed limiter device, speed limit 60 km/hour
Brake system ABS (4S / 4M)
Fuel tank Min-200 L / aluminum alloy fuel tank/
Others

/ The vehicle meets the conditions of adapting to the working conditions of

the plateau and cold regions./
Steering wheel

Left

HT457 rear dual drive axle (drum)
Axle’s loading capacity kg 6500 / 7000 / 17500
Loading kg 25000
Over all weight kg 35000
Dimension of the machine and equipment mm 11360×2500×3750
Mixing charger device of material Stainless steel
Amount of explosives kg 15000
Emulsion/ANFO ratio % 70/30
Borehole charging depth m 20-30
Borehole charging speed

kg/min

Wed Borehole: 200--280kg/min

Dry Borehole: 300--450kg/min

Measurement error, % ± 2
Borehole charging diameter

mm

 70-320

Storage tank for produced emulsion

/equipment/

M3/kg/

Min-8,4

/10500/

Porous ammonia container

/equipment/

M3/kg

Min-3,4

/4500/

Water tank volume,

/equipment/

м3

Min-0.4

Sensor tank volume

/equipment /

м3

Min-0.5

Volume of sodium nitrite storage tank

/equipment/

Thre are two.

1

0.15m3/150kg

2 0.15m3/150kg

Diesel fuel tank volume,

/equipment/

м3

Min-1.0
Charger hose length м Min-25
Location of tank loading Pour over the tank loading

Other detail equipment:

Item Name Quantity
1

Axial piston pump

83032917 FR-R-090C-LS-20-20-NN-N-3-S1A2-A1N-NNN-NNN-NNN

 2
2

Rear pump

KR-R-038C-LS-26-20-NN-N-3-C2AG-A6N-PLB-NNN-NNN

 1
3 RAVEN pump R1-10-3-0/STD/SS 1
4 Screw pump NM063SY02S18V 1
5 Cycloid motor 101-1028(RAVEN pump) 1
6 Cycloid motor OMS-160(reel) 1
7 Cycloid motor 112-1066(MONO pump) 1
8 Gear motor EM4(Fuel motor) 1
9 Hydraulic components 1 set
10 Hydraulic cylinder 1
11 Cycloid motor 104-1068 1
12 Cycloid motor 104-1065 1
13 Cycloid motor 104-1063 2
14 Cleaning pump:CC7010 1
15 Cleaning motor:EM21 1
16 Fuel pump:EM25 1
17 Fuel Y type filter:YWU-160×180-J 1
18 Peristaltic pump:253Y-PPS/ZL-24V 2
19 Metal tube float flowmeter CP50R1DN20M2CI 1
20 Metal tube float flowmeter CP50R1DN15M2CI 1
21 Temperature Transmitter WZPJ-240 PT100 0~100℃ 1
22 2.5MPa Explosion relief valve 1
23

Two-wire pressure transmission 0-2.5MPa:

YSZ-100BH2F7

 1
24 2”Explosives delivery hose 30m
25 Industrial computer 1
26 Programmable Controllers 1
Front overhang: 1500/2305, 2280mm
Front track: 2022,2041 / 2022,2041mm
Rear track: 1830mm
Approaching departure angle: 16/15.

15t Heavy Anfo Sinotruk Howo 8x4 Truck BCZH-15G On - Site Mixed Heavy Ammonium Explosive Truck

15t Heavy Anfo Sinotruk Howo 8x4 Truck BCZH-15G On - Site Mixed Heavy Ammonium Explosive Truck

15t Heavy Anfo Sinotruk Howo 8x4 Truck BCZH-15G On - Site Mixed Heavy Ammonium Explosive Truck

15t Heavy Anfo Sinotruk Howo 8x4 Truck BCZH-15G On - Site Mixed Heavy Ammonium Explosive Truck

After-sale service:

Whole life truck technology support.

Original spare parts supplied.

Specialized technician team support.
