China Factory Directly 12000lbs 12V 24V off road 4x4 car T-clutch electric winch with synthetic rope
China Factory Directly 12000lbs 12V 24V off road 4x4 car T-clutch electric winch with synthetic rope
Specifications
Brand Name :
ROADBON4WD
Model Number :
RB-TC12000S-1
Place of Origin :
China
MOQ :
20
Price :
banke&roadbon4wd.com
Payment Terms :
T/T
Supply Ability :
500
Delivery Time :
20
Packaging Details :
carton
Description
China Factory Directly 12000lbs 12V 24V 4WD off road 4x4 car electric winch with synthetic rope T-clutch

Specification:

Rated Line Pull:12000LB(5443kg) single-line
Motor: 6.6hp/4.9kw 12V, series Motor
Gear Train: 3-stage planetary
Gear Reduction Ratio: 216:1 or 150:1
Clutch: turn 180°
Synthetic rope: φ9.5mm×27m
Drum Size: φ64mm×224mm
Overall Dimensions: (L×W×H) 21.9''x6.5''x10.2'' (557mmx165mmx260mm)
Duty Cycle:Intermittently
Fairlead:aluminium fairlead
Mounting Bolt Pattern: 10''x4.5''(254 x 114.3mm)
Remote Control: Included

Packing detail
Package: 1pc/box,(630x245x405mm)
Gross Weight:88lbs(40kg)


Dclivery:
30 days after payment
China Factory Directly 12000lbs 12V 24V off road 4x4 car T-clutch electric winch with synthetic rope
China Factory Directly 12000lbs 12V 24V off road 4x4 car T-clutch electric winch with synthetic rope
China Factory Directly 12000lbs 12V 24V off road 4x4 car T-clutch electric winch with synthetic rope
China Factory Directly 12000lbs 12V 24V off road 4x4 car T-clutch electric winch with synthetic rope
China Factory Directly 12000lbs 12V 24V off road 4x4 car T-clutch electric winch with synthetic rope
China Factory Directly 12000lbs 12V 24V off road 4x4 car T-clutch electric winch with synthetic rope

Our company's products are called "Chinese WARN" because of its superior performance. In the professional evaluation of the top ten winches in the world by the Australian professional magazine "4WD ACTION" in 2011, our winch won the first place in the comprehensive ranking.
