Warehouse Automatic Stacker 1 Ton 1.2 Ton 1.5 Ton Electric Pallet Stacker With 3m 3.5m Lifting Height
Warehouse Automatic Stacker 1 Ton 1.2 Ton 1.5 Ton Electric Pallet Stacker With 3m 3.5m Lifting Height
Warehouse Automatic Stacker 1 Ton 1.2 Ton 1.5 Ton Electric Pallet Stacker With 3m 3.5m Lifting Height
Warehouse Automatic Stacker 1 Ton 1.2 Ton 1.5 Ton Electric Pallet Stacker With 3m 3.5m Lifting Height
Warehouse Automatic Stacker 1 Ton 1.2 Ton 1.5 Ton Electric Pallet Stacker With 3m 3.5m Lifting Height
Warehouse Automatic Stacker 1 Ton 1.2 Ton 1.5 Ton Electric Pallet Stacker With 3m 3.5m Lifting Height
Warehouse Automatic Stacker 1 Ton 1.2 Ton 1.5 Ton Electric Pallet Stacker With 3m 3.5m Lifting Height
Warehouse Automatic Stacker 1 Ton 1.2 Ton 1.5 Ton Electric Pallet Stacker With 3m 3.5m Lifting Height
Specifications
Brand Name :
Bilon
Certification :
CE
Place of Origin :
China
MOQ :
1-10 pcs
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
3000pcs in a month
Delivery Time :
15 days
Packaging Details :
Carton or wooden package
Weight (KG) :
750kg
Fork Width :
160mm
Fork Length :
1150mm
Load Center :
600mm
Battery :
24/120Ah
lift height :
1.6m-5m optional
Description

Warehouse Automatic Stacker 1 ton 1.2 ton 1.5 ton Electric Pallet Stacker with 3m 3.5m lifting height

-- Wide-view Mast -- offer enhanced forward visibility, thus more efficiency and safty during operation

-- Solid Overhead Guard -- specially designed for additional security

-- Ergonomics Seat -- much more comfortable and fatigue- reliveable after long time operation

-- Powerful Engine -- imported brand engine ensures high performance, safty and efficiency

-- Super low & Non-slip step

Driving style
Rider
Load capacity Q
kg
1500/2000
Load center C
mm
600
Overall length L1
mm
1710
Overall width W
mm
800
Min.overall height H1
mm
1580
1830
2080
2330
Fork dimension L×b×m
mm
1150/1200×160×60
Outside width of forks D
mm
560/685
Ground clearance x
mm
29
Base distance L0
mm
1185
Wheel material
PU
Driving wheel size
mm
φ250×80
Front wheel size
mm
φ78×70
Balance wheel size
mm
φ150×75
Min. steering radius Wa
mm
1366
Min. width of aisle
mm
≥2300
Max. height of forks H
mm
2000
2500
3000
3500
Max. overall height H2
mm
2560
3060
3560
4060
Min. height of forks H3
mm
85
Free lift height H4
mm
Optional
Travel speed(laden/unladen)
km/h
3.5/4
Lift speed(laden/unladen)
mm/s
80/125
Lower speed(laden/unladen)
mm/s
150/100
Brake type
Electromagnetic
Power of driving motor
kw
0.75
Power of lift motor
kw
2.0
Battery capacity/voltage
Ah/V
120/80/24
Weight of battery
kg
52
Net weight(with battery)
kg
586
621
656
691

Warehouse Automatic Stacker 1 Ton 1.2 Ton 1.5 Ton Electric Pallet Stacker With 3m 3.5m Lifting HeightWarehouse Automatic Stacker 1 Ton 1.2 Ton 1.5 Ton Electric Pallet Stacker With 3m 3.5m Lifting HeightWarehouse Automatic Stacker 1 Ton 1.2 Ton 1.5 Ton Electric Pallet Stacker With 3m 3.5m Lifting Height
