Features
1. The wheel loader uses a hydro-mechanical transmission which can make full use of engine power and can have an automatic variable transmission according to the external resistance. It avoids power failure of the engine due to the suddenly increased external load. The wheel loader can absorb and eliminate the vibration and impact of external load on engine. It protects the drive system and engine, increases the service life, facilitates the operation and achieves higher economical and production efficiency.
2. The wheel loader uses a central articulated frame and load sensing hydraulic steering gear. The machine can achieve a short turning radius and superposition of the front and rear tracks upon turning (this will ensure safe driving). The wheel loader has the advantages of easy operation on narrow sites, flexible operation, safety, convenient maintenance and so on.
3. The wheel loader uses four-wheel drive, low-pressure wide base off-road tires and an oscillating rear axle, so it has sound off-road performance, good traffic ability andlarger traction.
4. The wheel loader is equipped with a single-pipe type hydraulic four-wheel brake.
5. The wheel loader has a fully enclosed cab and the seats have the functions of vibration reduction and easy adjustment. The machine offers the driver a comfortable drive and wide view.
Technical Specifications
Rated bucket capacity | 1.2M3 | Transmission system | |||
Rated loading weight | 2000kgs | Torque converter model | YJ-280A | ||
Operating weight | 5800kgs | Type | Single phase, 3-elements | ||
Auto. self-leveling system | Have | Gearbox type | Fixed shaft power shift | ||
Rated loading turn force | 4000kgf | Shifts (forward/reveres) | 2/2 | ||
Max. breakout force | 5467kgf | Max. traveling speed | 24km/hour | ||
Max. pulling force | 45.4kN | Tire | |||
Grade ability | 30 degree | Size | 16/70-20 | ||
Lifting time of arm | 5.9s (full load) | Front wheel pressure | 220kps | ||
Lowering time of arm | 2.8s (full load) | Rear wheel pressure | 180kps | ||
Tilting time of arm | 1.1s | Steering system | |||
Overall dimension | 5630x2120x2717mm | Steering angle | ± 35dgeres | ||
Engine | Mini. Steering radius | 5251mm | |||
Model | R4105G34 | Others | |||
Type | Water cooled, 4-strokes | Dumping clearance | 2622mm | ||
Bore x Stroke | 105x125mm | Dumping reach | 752mm | ||
Max. torque | 270Nm | Min. Ground clearance | 310mm | ||
Rated power | 55kW | Wheel base | 2400mm | ||
Min. oil consumption | ≦ 243g/ kw.h | Wheel tread | 1640mm | ||
Rated speed | 2200rpm | Max. bucket reach | 4092mm |
