Honda Gasoline Engine 1000kgs Tracked Concrete Dumper For Site Works CE / SGS / ISO
Honda Gasoline Engine 1000kgs Tracked Concrete Dumper For Site Works CE / SGS / ISO
Honda Gasoline Engine 1000kgs Tracked Concrete Dumper For Site Works CE / SGS / ISO
Honda Gasoline Engine 1000kgs Tracked Concrete Dumper For Site Works CE / SGS / ISO
Specifications
Brand Name :
Visbull
Model Number :
KD1000M
Certification :
CE/SGS/ISO
Place of Origin :
China
MOQ :
1unit
Price :
US$6500-US$7000 per unit
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1,000pcs per month
Delivery Time :
25-30 working days after received your advance payment
Packaging Details :
Nude packing in container.
Payload :
1000kgs
Max Pressure :
150bar
Hydraulic Motors :
2x Orbital
Engine :
B&S 13HP or HONDA GX390 13HP or CHINA Diesel Engine
Self Loading Shovel :
Yes
Track roller :
3
Max Travel Speed :
5.0 km/h
Dimensions :
1800*830*1170mm
Weight :
800kgs
Hydraulic Pump :
Piston Pump
Color :
Red
HS CODE :
8428909090
Standard Track Width :
180mm
Skip Tipping System :
Hydraulic
Transmission System :
Hydraulic System
Brake Parking :
Mechanical
Main Valve :
2-3way
Cooler System Oil :
Air
Description

Honda Gasoline Engine 1000kgs Tracked Power Barrow For Site Works CE / SGS / ISO

1tons Gasoline Engine Mini Dumper With

Self - Loading Shovel And Hydraulic Transmission


Specifications:

Specification

KD1000M

Tracked power barrow

Engine

Briggs&Stratton 13HP or HONDA GX390 13HP or

CHINA Diesel Engine

Weight:

800kg

Transmission system

Hydraulic system

Type: Hydrostatic

Hydraulic Pump: Piston Pump

Hydraulic Motors: 2x orbital

Max Pressure: 150bar(2180psi)

Brake Parking: Mechanical

Main Valve: 2-3way

Cooler system oil: air

Skip Tipping System: Hydraulic

Loading Capacity

1000kg

Standard Track Width

180mm(7.1in)

Track roller

3

Rockling rollers and track tensioning

Yes

Max Travel Speed

5.0 km/h

Dimension

180*83*117(retort stand)

SELF LOADING SHOVEL

Yes

HI-TIP

NO

Loading Capacity

20GP

6

40HP

13

Description:

1. The max loading weight is 1000kgs .

2. With B&S 13HP or HONDA GX390 13HP or Diesel Engine

3. Hydraulic Transmission case

4 . Efficiency of transportation by transportation, loading, unloading and dumping ability.

5. Hydraulic Pump Stepless Speed Changes

Competitive Advantage:

1 . Easy and comfortable operation due to the intuitive controls.
2 . Hydraustatic dumping from three sides, easily changed by screw pins
3 . Easy climing and stable crossing the obstacles.
4 . Spot turning, mini slipping.


Applications:

Dumpers are widely used in many different of site works, such as Building construction industry,

landscaping,gardening,farming,stables renting and so on.

Honda Gasoline Engine 1000kgs Tracked Concrete Dumper For Site Works CE / SGS / ISO
