1500kgs Site Works Concrete Dumper with 11KW Diesel Engine And Hydraulic Tipping Hopper 2WD
1500kgs Site Works Concrete Dumper with 11KW Diesel Engine And Hydraulic Tipping Hopper 2WD
1500kgs Site Works Concrete Dumper with 11KW Diesel Engine And Hydraulic Tipping Hopper 2WD
1500kgs Site Works Concrete Dumper with 11KW Diesel Engine And Hydraulic Tipping Hopper 2WD
Specifications
Brand Name :
Visbull
Model Number :
SD15-11D
Certification :
CE/SGS
Place of Origin :
China
MOQ :
1unit
Price :
US$4100-US$4200 per unit
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1,000pcs per month
Delivery Time :
25-30 working days after received your advance payment
Packaging Details :
Nude packing in container.
Payload :
1500kgs
Skip Capacity :
750L
Chassis :
Rigid Frame
Engine :
CHANGFA,S1100BNM
Driving :
4*2
Gradient :
21%
Turning Radius :
4m
Dimensions :
2917*1600*2100mm
Weight :
1200kgs
Starting System :
Electric start,12volts battery
Color :
Yellow
Rated Power :
11KW
Description

1500kgs Site Works Wheelbarrow with Engine 11KW Diesel And Hydraulic Tipping Hopper 2WD

1500kgs 2WD Mini Site Dumper With 11KW Diesel Engine And Hydraulic Tipping Hopper For Site Works
1.5tons Mini Dumper With Hydraulic Tipping Hopper

Specifications:

Model

SD15-11D

Drive Model

2WD

Length(mm)

2917

Width(mm)

1600

Height(mm)

2100

Wheel Base

Wheel Base(mm)

1500

Wheel Tread

Front Wheel(mm)

1320

Rear Wheel(mm)

1290

Min Ground Clearance(mm)

≥205

Dry Mass(Kg)

1500

Engine

Model

S1100BNM

Type

Horizontal single-cylinder four-stroke, radiator
water-cooled

12 Hours Rated Power(rpm)

11/2200

Tyre

Front Wheel

7.50-16

Rear Wheel

5.00-15

Clutch

Constant-contact, single-disc, dry clutch

Brake

Drum type with mechanical control

Steering Gear

Worm-and-double-roller type

Gear Box With

Selective-gear transmission, with three forward
speeds
and one reverse speed

Ground Speed (Km/H)

1st Gear

5.5

2nd Gear

11

3rd Gear

22

4th Gear

—

Reverse

4.8

Skip Capacity (m3)

0.75

Minimum Turning Radius (m)

4

Tipping System

Hydraulic Tipping hopper

Max, Grade Ability (%)

21

Electric Starting

Yes



Description:

1 . Wheel type mini dumper
2 . With power steering and powerful 15HP engine , it's easier to move at slope or rugged area .
3 . with transmission for car , it's possible to change speed during travel.
4 . Efficiency of transportation by transportation , loading , unloading and dumping ability.
5 . 4*2 driving articular frame with hydraulic steering
6 . China made F3L912 air cooled diesel engine with Deutz technology / NB485 water engineering
diesel engine

Applications:

Dumpers are widely used in many different of site works , such as the construction industry, the factory
floor , battlefield ,protecting road section , the municipal engineering , underground mines and so on .

Competitive Advantage:

1 . As a low volume, short distance transport of bulk materials for small site dumpers, because of its easy
operation, small turning radius can be used in a narrow environment, etc,.
2 . Full Cover of Diesel Engine
3 . Strong and Heavy Duty Frame and Chassis
4 . Bucket can be full automatically tipped by hydraulic cylinder
5 . Direction change of dumper can be easily controlled by hydraulic steering wheel
