Direct Injection Diesel Engine ZL20F Wheel Loader for Urban Construction / Agricultural Engineering
Direct Injection Diesel Engine ZL20F Wheel Loader for Urban Construction / Agricultural Engineering
Direct Injection Diesel Engine ZL20F Wheel Loader for Urban Construction / Agricultural Engineering
Direct Injection Diesel Engine ZL20F Wheel Loader for Urban Construction / Agricultural Engineering
Direct Injection Diesel Engine ZL20F Wheel Loader for Urban Construction / Agricultural Engineering
Direct Injection Diesel Engine ZL20F Wheel Loader for Urban Construction / Agricultural Engineering
Direct Injection Diesel Engine ZL20F Wheel Loader for Urban Construction / Agricultural Engineering
Direct Injection Diesel Engine ZL20F Wheel Loader for Urban Construction / Agricultural Engineering
Specifications
Brand Name :
Visbull
Model Number :
ZL20F
Certification :
CE/EMARK/GHOST/ISO
Place of Origin :
CHINA
MOQ :
1 unit
Price :
negotiation
Payment Terms :
L/C at sight, T/T or western Union
Supply Ability :
1200 units per month
Delivery Time :
10 working days after received L/C or your deposit
Packaging Details :
Naked packing in container
Product name :
Wheel loader
Rated power :
55KW
Rated loading weight :
2 ton / 2000KG
Operating weight :
5310KG
Rated bucket capacity :
1.2 CBM
Dumping reach :
752 mm
Dumping clearance :
2600 mm
Max.break out force :
5476kgf
Description

Direct Injection Diesel Engine ZL20F Wheel Loader for Urban Construction / Agricultural Engineering

2000 kg capacity 1.2M3 Bucket 4WD mini Wheel Loader ZL20F with new hood

Feature:

1. Using direct injection diesel engine as power, with easy startup and low oil consumption
2. Using special drive axle, with strong ability to overcome obstacle
3. Chassis uses hinged structure, with small turning radius and flexible turning, which applies to the operation in narrow space
4. This machine uses hydraulic operation, with simple structure, convenient operation, good performance and reliable quality
5. Widely applying to the construction of agricultural engineering and small and medium building such as road, coal mine, brickyard, urban construction, kiln factory, stone material factory, prefabricated cement parts factory, etc.

Specification

Rated bucket capacity

1.2M3

Rated loading weight

2000kgs

Operating weight

5310kgs

Auto. self-leveling system

Have

Rated loading turn force

4000kgf

Max. breakout force

5467kgf

Max. pulling force

45.4kN

Grade ability

30 degree

Lifting time of arm

5.9s (full load)

Lowering time of arm

2.8s (full load)

Tilting time of arm

1.1s

Overall dimension

5630x2100x2850mm

Engine

Model

4DX21-72

Type

Water cooled, 4-strokes

Bore x Stroke

105x125mm

Max. torque

270Nm

Rated power

55kW

Min. oil consumption

≦ 243g/ kw.h

Rated speed

2200rpm

Transmission system

Torque converter model

YJ-280A

Type

Single phase, 3-elements

Gearbox type

Fixed shaft power shift

Shifts (forward/reveres)

2/2

Max. traveling speed

24km/hour

Tire

Size

16/70-20

Front wheel pressure

220kps

Rear wheel pressure

180kps

Steering system

Steering angle

± 35degrees

Mini. Steering radius

5251mm

Others

Dumping clearance

2600mm

Dumping reach

752mm

Min. Ground clearance

310mm

Wheel base

2400mm

Wheel tread

1640mm

Max. bucket reach

4092mm
