Diesel Engine Steel / Rubber Track Mini Crawler Bulldozer for Agriculture Use
Diesel Engine Steel / Rubber Track Mini Crawler Bulldozer for Agriculture Use
Diesel Engine Steel / Rubber Track Mini Crawler Bulldozer for Agriculture Use
Diesel Engine Steel / Rubber Track Mini Crawler Bulldozer for Agriculture Use
Diesel Engine Steel / Rubber Track Mini Crawler Bulldozer for Agriculture Use
Diesel Engine Steel / Rubber Track Mini Crawler Bulldozer for Agriculture Use
Diesel Engine Steel / Rubber Track Mini Crawler Bulldozer for Agriculture Use
Diesel Engine Steel / Rubber Track Mini Crawler Bulldozer for Agriculture Use
Specifications
Brand Name :
Visbull
Model Number :
C702
Certification :
Ghost/ISO
Place of Origin :
China
MOQ :
1 unit
Price :
negotiation
Payment Terms :
L/C at sight, T/T or western Union
Supply Ability :
1500 units per month
Delivery Time :
30 working days after received L/C or your deposit
Packaging Details :
Naked packing
Product Name :
Mini bulldozer
Wheel base :
1622 mm
Engine flywheel power :
58.8KW / 80HP
Ground pressure(without ripper) :
47.4 KPa
Operating weight(not including ripper) :
6630 KGS
Track width :
390 mm
Lifting force :
14 kn
Track gauge :
1435 mm
Description

Diesel Engine Steel / Rubber Track Mini Crawler Bulldozer for Agriculture Use

Mini Crawler Bulldozer C802 , 80HP Power, for Engineering Construction , Agriculture Use

Feature:

1. The 70-90HP crawler tractor is manufactured with fully enclosed cab. Heating system, air condition, and audio system are optional. Besides the broad vision, users can also enjoy the nice appearance and the comfortable operation.

2. For optimal trafficability and steering performance, this range of agricultural vehicle can be designed with rubber track.

3. The utilization of hydraulic power steering gear greatly reduces driver’s labor intensity.

4. To obtain good reliability, our rubber tracked crawler adopts simple beam structure for the final gear.

5. The new seal structure for the rear gear of our 70-90HP crawler tractor can reduce the steering oil intake.

6. The crawler tractor with cab adopts (4F+2R) sliding-gear transmission. The reasonable gear range makes it suitable for farmland and bulldozing.

7. Equipped with the diesel engine produced on the basis of British technology, our diesel crawler tractor is quite popular due to the large torque, powerful overload capacity, low fuel consumption, and environmental protection.

Specification:

Type C802
Overall dimensions L×W×H (mm) (With blade) 4870×2462×2766
Overall dimensions L×W×H (mm)(Without blade) 4466×1835×2766
Operating weight (kg) (With blade) 6630
Track gauge (mm) 1435
Wheel base (mm) 1622
Track width (mm) 390
Ground pressure (kPa) (With blade) 47.4
Engine
Engine type LR4A3Z-22
Rated power output (kW) 58.8
Rated speed (r/min) 2200
Gear box
Number of speed gear (forward/reverse) 4/2
Speed range(Km/h) forward/reverse 3.67~9.03/3.51~5.59
PTO shaft power (KW) 49
PTO rotational speed (r/min) 750
Working device
Type of linkage Postposition double-point linkage or three-point class two linkage
Depth control method Height adjustment
Lifting force(KN) 14
Blade dimensions height ×width(mm) 2462×850
Drop below ground (mm) 290

Diesel Engine Steel / Rubber Track Mini Crawler Bulldozer for Agriculture Use
