XCMG Cold Vertical Milling Machine for Main Asphalt Concrete Road Maintenance
XCMG Cold Vertical Milling Machine for Main Asphalt Concrete Road Maintenance
XCMG Cold Vertical Milling Machine for Main Asphalt Concrete Road Maintenance
XCMG Cold Vertical Milling Machine for Main Asphalt Concrete Road Maintenance
XCMG Cold Vertical Milling Machine for Main Asphalt Concrete Road Maintenance
XCMG Cold Vertical Milling Machine for Main Asphalt Concrete Road Maintenance
XCMG Cold Vertical Milling Machine for Main Asphalt Concrete Road Maintenance
XCMG Cold Vertical Milling Machine for Main Asphalt Concrete Road Maintenance
Specifications
Brand Name :
Visbull
Model Number :
XM200E
Certification :
ISO9001:2008, CE
Place of Origin :
China
MOQ :
1 unit
Price :
negotiation
Payment Terms :
L/C at sight, T/T or western Union
Supply Ability :
1500 units per month
Delivery Time :
10 working days after received L/C or your deposit
Packaging Details :
Naked packing in container
Product Name :
Cold milling machine
Rated power :
353kw
Max. milling depth :
300mm
Max. milling width :
2000mm
Travel speed :
0-5km/h
Operating speed :
0-34m/min
Drum diameter with tools :
980mm
Operating weight :
28500kg
Description

XCMG Cold Vertical Milling Machine for Main Asphalt Concrete Road Maintenance

XCMG XM200E Vertical Milling Machine Operations Cold Milling Machine With 2M Max. Milling Width

Specification:

Model

　

XM200E

　

Max. milling with

mm

2000

　

Max. milling depth

mm

300

Milling wheel

Number of tools

　

162

Drum diameter with tools

mm

980

Engine

Model

　

DHP12

Rated power

kW

353

Rated speed

rpm

2100

Specifications

Operating speed

m/min

0～34

Travel speed

km/h

0～5

Ground clearance

%

80

Ground clearance

mm

≤320

Operating weight

kg

28500

Volume

Fuel tank

L

800

Hydraulic oil tank

L

300

Water tank

L

2300

Conveyor

Width

mm

800

Measurement

Overall machinery LxWxH

mm

6750×2500×2900

Conveyor LxWxH

mm

8000×1150×900

Travel mode

　

Track

XM Series milling machine is one of the main asphalt concrete road maintenance equipment, mainly used for large-scale highways, urban roads, airports, freight yard, etc for renovation of asphalt pavement. One-time removal of entire concrete overlay. It can also be used for cleaning protuberance, oil layers, retieulation and vehicle tracks as well as road trench, tunnel excavation. cement road surface roughening and dislocation smothness.
The equipment features advanced performance, high efficiency, simple process, easy control of milling depth, flexible operation, good maneuverability and the old material recycling and utilization. It is an ideal equipment for pavement maintenance and renovation.

Performance and characteristic:

1. The milling drum is driven by two four-link belts with automatic tensioning drvice.

2. The moving system is the four-wheel fully hydraulic driving .The differential lock makes uniform driving

forces even on the slippery road surface.

3. The machine has the advantages of being suitable for different milling materials and milling depth,

optimizing power output automatic adjusting function and implementing maximization of the productivity.

4. The brake system implements the travelling brake by the reverse dragging of the hydraulic system.The

multi-disc typed brake is arranged on the rear wheel reducer to implement the parking brake. The automatic

depth control (selectable )adopts the contact-typed or non contact-typed sensor for detection with digitally displayed milling depth

XCMG Cold Vertical Milling Machine for Main Asphalt Concrete Road Maintenance
