176KW Deutz Diesel Engine XCMG Road Paving Machinery for Asphalt Driveway Paving
176KW Deutz Diesel Engine XCMG Road Paving Machinery for Asphalt Driveway Paving
176KW Deutz Diesel Engine XCMG Road Paving Machinery for Asphalt Driveway Paving
176KW Deutz Diesel Engine XCMG Road Paving Machinery for Asphalt Driveway Paving
Specifications
Brand Name :
Visbull
Model Number :
RP1356S
Certification :
CE/SGS
Place of Origin :
China
MOQ :
1Unit
Price :
Negotiation
Payment Terms :
D/A, L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500pcs per month
Delivery Time :
25-30working days after received your payment
Packaging Details :
Nude packing in container.
Basic Working Width :
3m
Max. Working Width :
12m
Max. Paving Thickness :
350mm
Paving Speed :
18Km/h
Hopper Capacity :
15tons
Gradient Ability :
20%
Rated Output :
176KW
Dimensions :
6660×2656×3880mm
Weight :
23.5～32.5tons
Fuel Tank Capacity :
310L
Description

176KW Deutz Diesel Engine Road Paving Machinery for Asphalt Driveway Paving


XCMG 12m Multi - Function Asphalt Paving Machine RP1356S With 176KW Deutz Diesel Engine
12m XCMG Multi - Function Asphalt Concrete Paver RP1356S
Specifications:

ltem

Unit

Parameter

Theoretical productivity

t/h

900

Max working Width

m

12

Max Paving Thickness

mm

350

Paving Speed

m/min

18

Flatness

mm/3m

0.8

Compactness

%

≥90

Dense irregularity

%

＜4

Traveling Speed

km/h

3.2

Drive type

Crawler

Gradient Ability

%

20

Hopper Capacity

t

15

Hopper Width

mm

3500

Hopper Length

mm

2280

Engine Type

DEUTZ BF6M1013ECP

Rated Output

KW

176

Speed

rpm

2300

Fuel Tank Capacity

L

310

Weight

t

23.5～32.5

Overall Dimension

mm

6660×2656×3880


RP1356S asphalt paver has good reliability, economy and adaptability, advanced
machine technology performance, high job quality, energy efficient. It can be widely
used in various grades of asphalt concrete paving surface layer and construction,
highway construction is an important construction equipment.

1. Using Full CAN bus network control systems, integrated intelligent paving job management system, using patented technology to achieve the overall number of
invention various systems to run concurrently, precise control, thus meet high
standards of highway asphalt surface construction requirements.

2. Configure Four strong composite radiator, through compulsory centralized heat,to
ensure continuous work long hours at an ambient temperature of 50 ℃ temperature

3 independently driven, digital microcomputer control, low-speed stability.The new feeding system.

4. long oversized by design for different material vehicle needs to meet the need of continuous paving

5. lose points about material using four sets of independent full hydraulic
transmission, level ultrasonic sensor control technology, to achieve full-scale
uniform feed.

6. Configure and other vibration strength through optimization and structural rigidity
to strengthen the design of the screed, the overall vibration stability, and anti torsion
ability, paving flatness and dense high.

176KW Deutz Diesel Engine XCMG Road Paving Machinery for Asphalt Driveway Paving
