Specifications
Brand Name :
Visbull
Model Number :
JC45
Certification :
CE/Ghost/Emark/ISO
Place of Origin :
CHINA
MOQ :
1 unit
Payment Terms :
Western Union, MoneyGram, L/C, T/T
Supply Ability :
2000 units per month
Delivery Time :
10 days after receipt of deposit or L/C
Packaging Details :
Naked Packing in Container
Rated Power :
50 HP
Rated Operating Capacity :
700 Kg
Bucket Capacity :
0.36 m3 - 0.45 m3
Weight :
2750 Kg
Max.Travel Speed :
12 m/h
Grade ability :
20 °
Tipping load :
1400 Kg
Lifting Force :
1600 Kg
Description

Hydraulic Electric Skid Steer Loader , 20 ° Grade Ability Skid Steer Track Loader

4WD 50HP Power Skid Steer Loader JC45 With Bobcat Attachments Operating Weight 2750kg

Main Features of skid steer loader:

1) Good technical parameters with competitive price
2) maneuver in tight spaces, turn within its own length
3) a broad product line, innovative designs, and unsurpassed range of job-matched attachments.
4) Excellent reach & lift height for truck loading (vertical path).
5) more than 20 series attachments for option: pallet fork, swing blade, utility fork grapple, asphalt cutter, backhoe, hydraulic hammer, 4 in 1 bucket, auger, cultivator, and tooth bucket etc
6) attachment can be used with bobcat type skid loader
7) world famous hydraulic systems from America, Japan and Italy
8) famous brand engine with EPA or EC stage II or III from abroad and domestic
9) CE and ISO 9001 certificated
10) versatility, maneuverability and reliability

OPTIONAL:
1) PERKINS ENGINE, HYUNDAI ENGINE, DEUTZ ENGINE, LOVOLE ENGINE AND DOMESTIC ENGINE AND MORE
2) WITH OR WITHOUT HYDRAULIC SERVO(JOYSTICK SYSTEM)
3) ENCLOSED CAB WITH OR WITHOUT AIR CONDITIONER OR HEATER
4) ALL KINDS OF TIRES ( SOLIC, NORMAL, CACUUM) AND DIFFERENT TYPE FOR CHOICE
5) VARIOUS OF ATTACHMENTS

Specifications 　
Rated operating capacity(kg) 700
Tipping load(kg) 1400
Bucket capacity(m3) 0.36-0.45
Operationg weight(kg) 2600
Max. travel speed(km/h) 12
Hydraulic pump flow(L/min) 62.5
Fuel tank capacity(L) 50
Tires 10.0/75-15.3
Overall dimensions(mm) 3200×1740×2030
Dimensions 　
Height at maximum extension(mm) 3670
Height to bucket hinge pin(mm) 2900
Width with bucket(mm) 1740
Track width(mm) 1450
Wheelbase(mm) 991
Ground clearance(mm) 185
Dump angle 40°
Dumping height(mm) 2310
Maximum reach(mm) 710
Engine 　
Maker/Model XINCHAI 490BPG
Net power 50hp/2650rpm
Type 4 Cylinder in-line, Water cooled, 4 stroke, Diesel engine
Displacement(L) 2.54
Standard 　
Open-type operator cab 　
Hand control system(Mechanical type) 　
Standard bucket 　
Auxiliary hydraulic couplers 　
Optional 　
Enclosed operator cab with A/C 　
Cab fitted with a heater as standard 　
Hydraulic joystick controls 　
Attachments: Backhoe,Breaker,Angle blade,Auger,Sweeper,Pallet fork,Combinition bucket,Mower,Asphalt cutter,and More

Hydraulic Electric Skid Steer Loader , 20 ° Grade Ability Skid Steer Track Loader

Hydraulic Electric Skid Steer Loader , 20 ° Grade Ability Skid Steer Track Loader
