Hard Water Well Drill Bits T45 89mm Ballistic Mining Drill Bits 4 Flushing Holes
Hard Water Well Drill Bits T45 89mm Ballistic Mining Drill Bits 4 Flushing Holes
Hard Water Well Drill Bits T45 89mm Ballistic Mining Drill Bits 4 Flushing Holes
Hard Water Well Drill Bits T45 89mm Ballistic Mining Drill Bits 4 Flushing Holes
Hard Water Well Drill Bits T45 89mm Ballistic Mining Drill Bits 4 Flushing Holes
Hard Water Well Drill Bits T45 89mm Ballistic Mining Drill Bits 4 Flushing Holes
Hard Water Well Drill Bits T45 89mm Ballistic Mining Drill Bits 4 Flushing Holes
Hard Water Well Drill Bits T45 89mm Ballistic Mining Drill Bits 4 Flushing Holes
Specifications
Brand Name :
MIROC by KSQ
Model Number :
R1489-T45
Certification :
ISO9001
Place of Origin :
China (Mainland)
MOQ :
5 Pieces
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100000 Pieces per Year
Delivery Time :
5-15 Working Days
Packaging Details :
Carton Box or Wooden Box
Product Name :
Thread Button Bit
Machine Type :
Hydraulic & penumatic Drill
Use :
water well, quarries, open pit and underground mining, construction, and blasting and so on.
Connection :
T45 Drifter rod, T45 Speed rod
Button Type :
Ballistic
Color :
Green black, customized
Description

Mining Tools Hard Water Well Drill Bits T45 89mm Retractable Thread Button Drill Bits Ballistic Button Drill Bit Stable

All KSQ' bits are computer aided designed and engineered, CNC manufactured and multiple heat-treated, to extend the product life for maximum wear and performance in the toughest of drilling conditions. Moreover, they are produced from premium steels and fitted with tips made from high quality tungsten carbide for superior penetration while maintaining high cleaning action at the face of the bit, to ensure maximum service life and impact strength. In addition, we have available full range of skirt shapes, front designs and cutting structures configuration for various rock formation as well as different penetration need.

How to choose the bit tooth type:

Spherical buttons: The height of exposed teeth is low, mainly used in the very hard rock formation above F14, to improve wear resistance, to prevent the situation of debris, it should take lower drilling speed.

Ballistic buttons: It can expose more height of buttons, mainly used in soft rock and ordinary rock below F12, with quicker drilling speed, but encountered hard rock, very easily to happen buttons debris phenomenon.

Products Parameters:

Product Name: Thread Button Drill Bit
Diameter: 89mm
Button Size: Front 14*12mm
Thread: T45
Flushing Hole: 2 Front and 1 Side
Application: Button drill bits are used in granite and marble quarry, gold mine, railway, tunnel, etc. for drilling
Weight: 5.4 kg
Button Type: Spherical
Body Type: Retract
Face Type: Drop Center
Material: Alloy steel bar 45CrNiMoV and tungsten carbide tips YK05
MOQ: No requirement for testing and trial order

We can design and manufature according to your requirment of diameter, number air holes and carbide button shape

Main Features:

1. Material:45CrNiMoV

2. Flushing Holes:4

3. More Thread Type:T38,T45,T51 etc

4. Carbide Length:0.5mm longer than other manufacturer so the carbides won't fall.

Why we choose YK05 tungsten carbides:

1 .high footage speed;

2. High wear resistance.

3. Suitalbe for 98% rocks.

Hard Water Well Drill Bits T45 89mm Ballistic Mining Drill Bits 4 Flushing HolesHard Water Well Drill Bits T45 89mm Ballistic Mining Drill Bits 4 Flushing Holes

Specification of other Button Drill Bits:

Diameter T.C buttons Flushing hole Angle Weight
mm inch Gauge x mm Front x mm Side Front Gauge Kg
76 3 6x12 4x11 1 2 40° 3.08
76 3 6x13 3x12,1x11 1 3 35° 3.16
76 3 8x12 4x12 1 2 35° 3.15
76 3 8x12 5x11 1 2 35° 3.09
89 31/2 8x13 4x13 1 2 35° 4.52
89 31/2 8x13 4x11,1x11 1 4 35° 4.35
89 31/2 8x13 4x11,2x9 1 4 35° 4.28
89 31/2 8x14 5x12 1 2 35° 4.58
89 31/2 8x13 6x12 1 2 35° 4.42
89 31/2 9x12 6x10 1 3 35° 4.62
102 4 8x15 4x15 1 2 35° 7.38
102 4 8x14 4x12,1x12 1 4 35° 7.25
102 4 8x14 4x12,2x12 1 4 35° 7.28
102 4 8x14 6x12 1 2 35° 7.15
102 4 9x13 8x13 1 3 35° 7.42
115 41/2 8x15 4x13,2x13 1 4 35° 9.54
115 41/2 8x15 7x14 1 2 35° 9.75
115 41/2 9x14 8x14 1 2 35° 9.72
127 5 8x16 7x14 1 2 35° 12.15
127 5 9x16 8x14 1 3 35° 14.42

Hard Water Well Drill Bits T45 89mm Ballistic Mining Drill Bits 4 Flushing Holes

Hard Water Well Drill Bits T45 89mm Ballistic Mining Drill Bits 4 Flushing Holes
