Concave Face Rock Drill Bits Low Pressure Dth Button Bits Dia 90mm
Concave Face Rock Drill Bits Low Pressure Dth Button Bits Dia 90mm
Concave Face Rock Drill Bits Low Pressure Dth Button Bits Dia 90mm
Concave Face Rock Drill Bits Low Pressure Dth Button Bits Dia 90mm
Concave Face Rock Drill Bits Low Pressure Dth Button Bits Dia 90mm
Concave Face Rock Drill Bits Low Pressure Dth Button Bits Dia 90mm
Concave Face Rock Drill Bits Low Pressure Dth Button Bits Dia 90mm
Concave Face Rock Drill Bits Low Pressure Dth Button Bits Dia 90mm
Specifications
Brand Name :
MIROC by KSQ
Model Number :
CIR90
Certification :
ISO9001
Place of Origin :
China (Mainland)
MOQ :
1 Pieces
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
5-15 Working Days
Packaging Details :
Carton Box or Wooden Box
Name :
CIR90 DTH button bit
Material :
Steel and Tungsten Carbide
Processing Type :
Forging
Use :
Mining Quarry Well Drilling
Usage :
Down the Hole Drilling
Face type :
Concave Face
Button type :
Ballistic Button
Bit Diameter :
90mm-120mm
Description

CIR90 Low Pressure DTH Button Bits Dia90mm for rock well mine drilling

Product Description

The CIR90 DTH bit is the tool cutting rock. Miroc CIR90 DTH bit for mining is made of superior quality alloy steel .Besides, all our DTH bit is using best quality carbides. In addition art manufacturing technology makes our CIR90 DTH bit for mining is with higher and more reliable quality.

Our DTH hammer and bits are compatible with CIR, DHD, QL,SD,Mission, etc. series of Atlas and etc. They are with high efficiency, low failure rate and long service life. They are with high efficiency, low failure rate and long service life, which can realize efficient and economical drilling even for all kinds of high hardness, high abrasive rocks and other harsh conditions.

Product Advantage

Independently researched and developed alloys with high strength and good abrasion resistance.

Different face style makes DTH bit is suitable for various rock conditions.

Flat face: This is an universal design, especially for hard and abrasive rock formation. So typically, flat face with hemi-spherical buttons design is the most popular choice.

Convex face: A classic design for soft to medium hard rock formation which is not so abrasive. This design have very excellent penetration rate but poor in hole deviation if rocks are hard.

Concave face: Medium hard to hard rock formations which is less abrasive and fractured. Especially for deep hole drilling, excellent control over hole deviation.

Bit designs and rock types
Concave Face Rock Drill Bits Low Pressure Dth Button Bits Dia 90mm

Products Parameters

Product

CIR90 DTH bit

Air pressure

Low
Diameter 90mm

Face type

Convex face

Carbide button shape

Ballistic

Drill rock type

Granite, Marble, Limestone, Basalt, ect.

Project types

Blast holes,/Quarry/Anchoring/Infrastructure/Geothermal holesWell drilling,ect.

Concave Face Rock Drill Bits Low Pressure Dth Button Bits Dia 90mmConcave Face Rock Drill Bits Low Pressure Dth Button Bits Dia 90mm

Low Air Pressure DTH Button Bit

Type Dia. Spline No. Weight (Kg)
CIR65
CIR70
CIR80
CIR80X
CIR90
CIR90
CIR90
CIR110
CIR110
CIR110W
CIR110W
CIR150
CIR150A
CIR150A
CIR170
CIR170A
CIR200W		 68
76
83
83
90
100
130
110
123
110
123
155
155
165
175
185
200		 6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6		 2.50
3.40
3.45
3.50
3.50
4.50
9.50
6.40
8.50
6.50
8.80
12.0
12.5
14.0
15.5
16.0
48.0

Specification of other DTH Bits

Specification: Diameter: (mm) Weight: (kg)
Low air pressure DTH bits CIR type 68 ~ 200 2.6 ~ 48
Middle air pressure BR & COP type 76 ~ 110 3.8 ~ 15
3 inch high Air pressure DTH bits(COP32/BR3/HD35/IR3.5/COP34/QL30) 85 / 90 / 95 / 100 / 105 4.2 ~ 5.5
4 inch high Air pressure DTH bits(HD45/DHD340A/COP44/SD4/QL40/HM4) 105 / 110 / 115 / 120 / 127 9 ~ 12
5 inch high Air pressure DTH bits(HD55/DHD350R/COP54/SD5/QL50/HM5) 133 / 140 / 146 / 152 / 165 15 ~ 18.5
6 inch high Air pressure DTH bits(HD65/DHD360/COP64/SD6/QL60/HM6) 152 / 165 / 178 / 190 / 203 26 ~ 36
8 inch high Air pressure DTH bits(HD85/DHD380/COP84/SD8/QL80/HM8) 195 / 203 / 216 / 254 / 305 33 ~ 95

How to order

Shank Type + Diameter + Face Design + Button Configuration

Company Information

The MIROC® Rock Drilling Tools product line by KSQ Technologies (Beijing) Co.Ltd. is the result of years of advanced engineering, precision manufacturing, and dedication to the use of high-quality materials. Rock Drilling Tools are used by many drilling professionals related to mining, construction, tunneling, and quarrying projects around the globe.

MIROC® Rock Drilling and Ground Support Tools include:

1. Low pressure DTH Hammer

2. Medium pressure DTH Hammer

3. High pressure DTH Hammer

4. DTH Drill bit

5. DTH Drill pipe

Concave Face Rock Drill Bits Low Pressure Dth Button Bits Dia 90mmConcave Face Rock Drill Bits Low Pressure Dth Button Bits Dia 90mm
