Carbide Insert Rock Mining Drilling Tools R32 64mm For Hydraulic Drilling Machine
Carbide Insert Rock Mining Drilling Tools R32 64mm For Hydraulic Drilling Machine
Carbide Insert Rock Mining Drilling Tools R32 64mm For Hydraulic Drilling Machine
Carbide Insert Rock Mining Drilling Tools R32 64mm For Hydraulic Drilling Machine
Carbide Insert Rock Mining Drilling Tools R32 64mm For Hydraulic Drilling Machine
Carbide Insert Rock Mining Drilling Tools R32 64mm For Hydraulic Drilling Machine
Specifications
Brand Name :
MIROC by KSQ
Model Number :
B1264-R32-B
Certification :
ISO9001
Place of Origin :
China (Mainland)
MOQ :
5 Pieces
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100000 Pieces per Year
Delivery Time :
5-15 Working Days
Packaging Details :
Carton Box or Wooden Box
Product Name :
Thread Button Bit
Usage :
Drifting and tunneling drilling
Diameter :
64mm
Thread :
R32
Weight :
1.6kg
Flushing Hole :
2 Front
Gauge Angle :
40 Degree
Button Type :
Ballistic
Description

High Quality R32 64mm Button Drill Bit Carbide Insert Mining Rock Drilling Tools for Hydraulic Drilling Machine

Product Description:

Thread button drill bit features:

Made from top quality steel and tungsten carbide as same as internationally well-known brand

Apply “hot-insertion” processing procedure to insert the buttons as same as internationally well-known brand

Optimized designs improve the drilling speed

Automatic production line ensure the quality stability

Military grade requirements of heat-treatment guarantee durability of the bits.

64mm R32 Tunneling Thread Rock Drill Button Bit is suitable for mining, quarrying, tunneling and so on. It is widely used for ground quarrying and underground drilling.

Products Parameters:

Product Name: Button Drill Bit
Diameter: 64mm
Button Size: Front 4*10mm Gauge 8*10mm
Thread: R32
Flushing Hole: 2Front
Application: Button drill bits are used in granite and marble quarry, gold mine, railway, tunnel, etc. for drilling
Weight: 1.6 kg
Button Type: Ballistc
Body Type: Standard
Face Type: Flat
Material: Alloy steel bar 45CrNiMoV and tungsten carbide tips YK05
MOQ: No requirement for testing and trial order

We can design and manufature according to your requirment of diameter, number air holes and carbide button shape


Product Advantage:

1. High footage speed;

2. High wear resistance.

3. Suitalbe for 98% rocks.

Carbide Insert Rock Mining Drilling Tools R32 64mm For Hydraulic Drilling Machine

Specification of other Retrac Button Bits:

Bit Dia.(mm) Thread NO. X Button Dia. NO.Flushing Holes(PCS) Weight(KG)
Gauge Front Side Front
51 R32 5×11 2×10 2 1 1.2
51 R32 6×10 3×9 　 3 1.2
57 R32 6×11 3×10 　 3 1.6
64 R32 6×11 3×11 1×9 1 3 2
64 T38 6×12 3×11 1 2 2
64 T38 8×10 4×10 1×9 　 4 2
76 T38 6×12 4×11 2 2 3.1
76 T38 8×11 4×11 1×11 　 4 3.1
76 T45 8×12 4×11 2 2 3.2
76 T45 8×12 4×11 1×11 　 4 3.2
78 T38 8×12 4×11 1×11 　 4 3.5
89 R32 8×12 5×11 　 2 4.1
89 R32 8×12 4×11 2×10 　 4 4.1
89 T38 8×12 5×12 2 2 4.8
89 T38 8×12 4×11 2×10 　 4 4.8
89 T45 8×12 6×12 2 2 5.1
89 T45 8×13 4×12 1×12 　 4 5.1
89 T51 8×12 6×12 2 2 5.1
89 T51 8×13 4×13 1×12 　 4 5.1
102 T45 8×12 7×12 　 2 6.5
102 T45 9×13 9×11 　 3 6.8
102 T45 8×14 4×12 2×11 　 4 6.8
102 T51 8×12 7×12 　 2 7.1
102 T51 9×13 9×11 　 3 6.5
102 T51 8×14 4×12 2×11 　 4 7.3
105 T45 8×14 6×13 　 2 7.1
115 T45 8×14 4×13 3×12 　 4 7.8
115 T45 9×14 10×12 　 3 7.9
115 T51 9×14 10×12 　 3 7.9
115 T51 8×14 7×13 　 2 9.6
115 T51 8×14 4×12 2×12 　 4 10.2
127 T45 8×14 8×13 　 2 11
127 T45 9×15 10×13 　 3 12.3
127 T51 9×15 10×13 　 3 12.3
127 T51 8×15 8×13 　 2 12
127 T51 8×14 4×14 4×12 　 4 12

Carbide Insert Rock Mining Drilling Tools R32 64mm For Hydraulic Drilling Machine
Carbide Insert Rock Mining Drilling Tools R32 64mm For Hydraulic Drilling Machine
