Reg Connection Dth Drill Pipe Water Well Drilling Machine Parts 114mm Out Diameter
Reg Connection Dth Drill Pipe Water Well Drilling Machine Parts 114mm Out Diameter
Reg Connection Dth Drill Pipe Water Well Drilling Machine Parts 114mm Out Diameter
Reg Connection Dth Drill Pipe Water Well Drilling Machine Parts 114mm Out Diameter
Reg Connection Dth Drill Pipe Water Well Drilling Machine Parts 114mm Out Diameter
Reg Connection Dth Drill Pipe Water Well Drilling Machine Parts 114mm Out Diameter
Specifications
Brand Name :
MIROC by KSQ
Model Number :
DTH Drill Pipe
Certification :
API, ISO9001
Place of Origin :
China (Mainland)
MOQ :
1 Piece
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100000 Pieces per Year
Delivery Time :
5-15 Working Days
Packaging Details :
Tray or Wooden Box
Material :
High Manganese Steel
Processing Type :
Forging
Usage :
Down the Hole Drilling
Diameter :
76mm-140mm
Length :
1000mm-6000mm
Wall Thickness :
5-12mm or As Requirement
Thread :
API 2 3/8'' REG
Weight :
30kg
Description

3 1/2 API REG Connection Water Well Drilling Machine Parts DTH Drill Pipe with 114mm Out Diameter

Drill pipes that are used in applications such as DTH/ DTHR/ DR basically comprise of a steel pipe with a pin at one end and a box on the other. The job of the drill pipe is to transmit rotational torque and thrust from the drill rig rotary head to down hole drilling tools.According to different application, different diameters of drill tubes are needed, basically, smaller DTH hammers need smaller DTH drill tubes, vice versa. Usually we are offering50mm,60mm,76mm,89mm,95mm,102mm,114mm127mm,140mm,159mmetc.

Product Features:
1. Materail: high quality low carbon steel to ensure good resistance to strench and tensile;
2. Outside Diameter: from 60mm to140mm, large diameter range;
3. Wall Thickness: two standards to suit for different requirements from domestic and international market;
4. Length: 1.5m,2m,3m,4m,6m and 9m to suit for different project requirement;
5. Process: friction welded to ensure the adaptor and pipe connect tightly as a whole set the cylic extrusion-compression ensure reliabile pipe;
6. Thread: API standard to ensure good adaptibility to your drill rig or hammer;
7. Staightness of pipe is high;
8. The weight is less to reduce the burden to equipment;

Products Parameters:

Pipe Diameter

 112mm

Wall Thickness

5mm, 6mm, 8mm

Pipe Length

1000 - 6000mm

Wrench flat

57/65 mm

Joints Connection

2 3/8‘’ REG

Trigger Slot

57/64.5
Technical Parameters of DTH Drill Pipe (Outer Flat Drill Rod):
Diameter
 Length Wrench Flats Threads
50-194mm 500-10700mm 40,57,65,75,83,95mm F42×10
F48×10
2 3/8''API REG
2 7/8''API REG
3 1/2''API REG
2 3/8''API IF 3 1/2"
BECO 4"BECO 4 1/2"
BECO 5 1/4"BECO

Usage:
1. Mining,water well, geothermal and all kinds of dth rock drilling.
2. Match to all kinds of DTH drill rig

Reg Connection Dth Drill Pipe Water Well Drilling Machine Parts 114mm Out Diameter

Specification of other DTH Pipes:

DTH drill pipes specifications
Outer diameter Thread 　 　
Wall thickness Length
mm inch mm mm
76 3 API 2 3/8 REG
API 2 7/8 REG
API 3 1/2 REG
API 4 1/2 REG
API 2 3/8 IF
API 2 7/8 IF
API 3 1/2 IF
API 4 1/2 IF
BECO 3 1/2"		 4 1000-6000
6.3
89 3.5 4 1000-6000
6.3
8.8
102 4 6.3 4000-6000
8.8
114 4.5 6.3 4000-9000
12.5
127 5 6.3 4000-9000
12.5
19
133 5.25 6.3 4000-9000
12.5
19
140 5.5 8.8 4000-9000
12.5
19

Reg Connection Dth Drill Pipe Water Well Drilling Machine Parts 114mm Out DiameterReg Connection Dth Drill Pipe Water Well Drilling Machine Parts 114mm Out Diameter
