Plug holes drilling pneumatic air rock drill Hand Held Rock Drill Hammer YT28
Plug holes drilling pneumatic air rock drill Hand Held Rock Drill Hammer YT28
Plug holes drilling pneumatic air rock drill Hand Held Rock Drill Hammer YT28
Plug holes drilling pneumatic air rock drill Hand Held Rock Drill Hammer YT28
Specifications
Brand Name :
MIROC
Model Number :
YT28 Jackleg hammer
Certification :
ISO
Place of Origin :
China
MOQ :
1 Set
Price :
negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
3000 per month
Delivery Time :
5-10workdays
Packaging Details :
Carton box, Wooden box
Color: :
Blue, Green
Weight: :
6-27kg
Model: :
Y6,Y20,Y24,YT24,YT27,YT28
Usage: :
Ore, Mining, quarrying, drilling,
Drill Depth: :
0.5-5m
Shank size: :
hex22x108mm
Description

YT28 Jackleg Hammer machines, pneumatic rock drill

Description & Specification

Product Name YT28 Rock drill pneumatic rock drill
Description The Series of pneumatic rock drills are mainly used in mines,railway,water irrigation works and quarrying works and quarrying works to drill hole or plug holes.It is suitable for wet or dry drilling in all kinds of rocks.
Drilling Direction Hand-held type for Perpendicular;Air-leg type for titling direction
Advantage Light weight;high efficiency,fast drilling velocity, low comsumption,convenient operation,long life part
MOQ No requriement for testing and trial order
Spare Parts Internal drill rod,plug hole rod,taper drill rod,thread drill rod,taper/thread drill bit

Specification of pneumatic rock drill/ jack hammer / Hand-operated rock drill

Hand Held Rock Drill Y6 Y8 Y20 Y24 Y26 YH24
Weight (kg) 6 8 18 24 26 24
Air consumption (L/s) ≤9.5 9.5 25 55 ≤47 55
Drill hole diameter (mm) 20 20-24 34-42 34-42 34-42 34-42
Max.drilling depth (mm) 0.5 0.5 3 3 5 5
Shank (mm) 15X88 22x108 22x108 22x108 22x108 22x108

Air-leg Rock Drill YT19A Y20LY YT24 YT27 YT28 YT29A
Weight (kg) 18 18 24 24 26 26.5
Air consumption (L/s) 28 ≤25 ≤67 ≤85 ≤81 ≤65
Drill hole diameter (mm) 34-42 34-42 34-42 34-42 34-42 34-45
Max.drilling depth (mm) 3 3 5 5 5 5
Shank (mm) 22x108 22x108 22x108 22x108 22x108 22x108

jack hammer | jack hammer | jack martelo | Jack Hammer | Presslufthammer | jack çekiç | Jack Hammer

Shipping in Container

Plug holes drilling pneumatic air rock drill Hand Held Rock Drill Hammer YT28Plug holes drilling pneumatic air rock drill Hand Held Rock Drill Hammer YT28Plug holes drilling pneumatic air rock drill Hand Held Rock Drill Hammer YT28Plug holes drilling pneumatic air rock drill Hand Held Rock Drill Hammer YT28
