Specifications
Brand Name :
MIROC
Model Number :
Airleg rock drill
Certification :
ISO
Place of Origin :
China
MOQ :
1 Set
Price :
negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
3000 per month
Delivery Time :
5-10workdays
Packaging Details :
Carton box, Wooden box
Color: :
Blue, Green
Weight: :
6-27kg
Model: :
pneumatic rock drill/ jack hammer / Hand-operated rock drill
Usage: :
Ore, Mining, quarrying, drilling,
Drill Depth: :
0.5-5m
Shank size: :
hex22x108mm
Certification: :
SGS
Description

YT28 hand held rock drilling machine / Portable Manual Pneumatic Mining Rock, perforadora compressor drilling

YT28 Jack leg drill:

The YT28 rock drill machine is a kind of high efficiency air leg rock drill machinery.It is mainly used for blasting holes and other drilling works in a quarries, railway construction, water conservancy construction and defence project facility. It is suitable for drilling and blasting under various of rocks at any direction angles.Blast hole dia is 3-42mm,drill hole depth is 5 m.

This machine may match with Model FT160BD short air leg or Model FT160BC long air leg.

This machine has transparent surface of FY200B oil reservoir to regulate oil.

Main parameter:

Weight ≈ 28 kg
Length 661mm
Cylinder dia 80mm
Piston stroke 60mm
Air pressure 0.4- 0.63MPa
Impact frequencey ≥ 37 Hz
Air consumption ≤81L/S
Air pipe (inner dia ) 25mm
Water pipe (inner dia ) 13mm
Drill bit dia 34-42mm
Shank dimensions(hex×length) 22×108±1mm/ 25×108±1mm
The function specification that Air pressure is 0.63Mpa
FY200B oil reservoir
Oil capacity 200ml

The optional for air leg of hand held rock drilling machine yt28

Air leg 160BD(Short air leg)
Length 1400mm
Push stoke 965mm
Cylinder diam. 65mm
Weight 14.4kg
Air leg FT160BC(Long air leg)
Length 1800mm
Push stoke 1365mm
Cylinder diam. 65mm
Weight 16.9kg

Description & Specification

Product Name YT28 Rock drill pneumatic rock drill
Application The Series of pneumatic rock drills are mainly used in mines,railway,water irrigation works and quarrying works and quarrying works to drill hole or plug holes.It is suitable for wet or dry drilling in all kinds of rocks.
Drilling Direction Hand-held type for Perpendicular;Air-leg type for titling direction
Advantage Light weight;high efficiency,fast drilling velocity, low comsumption,convenient operation,long life part
MOQ No requriement for testing and trial order
Spare Parts Internal drill rod,plug hole rod,taper drill rod,thread drill rod,taper/thread drill bit

Specification of pneumatic rock drill/ jack hammer / Hand-operated rock drill

Hand Held Rock Drill Y6 Y8 Y20 Y24 Y26 YH24
Weight (kg) 6 8 18 24 26 24
Air consumption (L/s) ≤9.5 9.5 25 55 ≤47 55
Drill hole diameter (mm) 20 20-24 34-42 34-42 34-42 34-42
Max.drilling depth (mm) 0.5 0.5 3 3 5 5
Shank (mm) 15X88 22x108 22x108 22x108 22x108 22x108

Air-leg Rock Drill YT19A Y20LY YT24 YT27 YT28 YT29A
Weight (kg) 18 18 24 24 26 26.5
Air consumption (L/s) 28 ≤25 ≤67 ≤85 ≤81 ≤65
Drill hole diameter (mm) 34-42 34-42 34-42 34-42 34-42 34-45
Max.drilling depth (mm) 3 3 5 5 5 5
Shank (mm) 22x108 22x108 22x108 22x108 22x108 22x108

jack hammer | jack hammer | jack martelo | Jack Hammer | Presslufthammer | jack çekiç | Jack Hammer

Package & Shipping
