pneumatic rock drill jack hammer Hand Held rock drill YT19A Y20LY YT27
pneumatic rock drill jack hammer Hand Held rock drill YT19A Y20LY YT27
pneumatic rock drill jack hammer Hand Held rock drill YT19A Y20LY YT27
pneumatic rock drill jack hammer Hand Held rock drill YT19A Y20LY YT27
pneumatic rock drill jack hammer Hand Held rock drill YT19A Y20LY YT27
pneumatic rock drill jack hammer Hand Held rock drill YT19A Y20LY YT27
Specifications
Brand Name :
MIROC
Model Number :
Airleg rock drill
Certification :
ISO
Place of Origin :
China
MOQ :
1 Set
Price :
negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
3000 per month
Delivery Time :
5-10workdays
Packaging Details :
Carton box, Wooden box
Color: :
Blue, Green
Weight: :
6-27kg
Model: :
pneumatic rock drill/ jack hammer / Hand-operated rock drill
Usage: :
Ore, Mining, quarrying, drilling,
Drill Depth: :
0.5-5m
Shank size: :
hex22x108mm
Type: :
with Airleg
Certification: :
SGS, SONCAP
drilling diameter: :
34-42mm
Description

YT19A, Y20LY, YT27 pneumatic rock drill/ jack hammer / Hand-operated rock drill

Apoplication

The Products are mainly used in construction sites, various types of mines, railways, water conservancy construction and national defense construction areas for drilling operations.

YT28 Jack leg drill:

The YT28 rock drill machine is a kind of high efficiency air leg rock drill machinery.It is mainly used for blasting holes and other drilling works in a quarries, railway construction, water conservancy construction and defence project facility. It is suitable for drilling and blasting under various of rocks at any direction angles.Blast hole dia is 3-42mm,drill hole depth is 5 m.

This machine may match with Model FT160BD short air leg or Model FT160BC long air leg.

This machine has transparent surface of FY200B oil reservoir to regulate oil.

YT28 pusher leg rock drill apply in hard rock on the rock drill operation,it has strong adaptability to the working conditions.The product is energy efficiency, Its components has long life and durable. The machice can be generally used with the same type,it can greatly reduce the customer loss for spare part replacement.

Description & Specification

Product Name YT28 Rock drill pneumatic rock drill
Description The Series of pneumatic rock drills are mainly used in mines,railway,water irrigation works and quarrying works and quarrying works to drill hole or plug holes.It is suitable for wet or dry drilling in all kinds of rocks.
Drilling Direction Hand-held type for Perpendicular;Air-leg type for titling direction
Advantage Light weight;high efficiency,fast drilling velocity, low comsumption,convenient operation,long life part
MOQ No requriement for testing and trial order
Spare Parts Internal drill rod,plug hole rod,taper drill rod,thread drill rod,taper/thread drill bit

Specification of pneumatic rock drill/ jack hammer / Hand-operated rock drill

Hand Held Rock Drill Y6 Y8 Y20 Y24 Y26 YH24
Weight (kg) 6 8 18 24 26 24
Air consumption (L/s) ≤9.5 9.5 25 55 ≤47 55
Drill hole diameter (mm) 20 20-24 34-42 34-42 34-42 34-42
Max.drilling depth (mm) 0.5 0.5 3 3 5 5
Shank (mm) 15X88 22x108 22x108 22x108 22x108 22x108

Air-leg Rock Drill YT19A Y20LY YT24 YT27 YT28 YT29A
Weight (kg) 18 18 24 24 26 26.5
Air consumption (L/s) 28 ≤25 ≤67 ≤85 ≤81 ≤65
Drill hole diameter (mm) 34-42 34-42 34-42 34-42 34-42 34-45
Max.drilling depth (mm) 3 3 5 5 5 5
Shank (mm) 22x108 22x108 22x108 22x108 22x108 22x108

jack hammer | jack hammer | jack martelo | Jack Hammer | Presslufthammer | jack çekiç | Jack Hammer

Shipping in Container

pneumatic rock drill jack hammer Hand Held rock drill YT19A Y20LY YT27pneumatic rock drill jack hammer Hand Held rock drill YT19A Y20LY YT27pneumatic rock drill jack hammer Hand Held rock drill YT19A Y20LY YT27
