7 degree 11 degree 12 degree 34mm 36mm 38mm 40mm Chisel Drill Bit for Hex22 Shank Rod
7 degree 11 degree 12 degree 34mm 36mm 38mm 40mm Chisel Drill Bit for Hex22 Shank Rod
7 degree 11 degree 12 degree 34mm 36mm 38mm 40mm Chisel Drill Bit for Hex22 Shank Rod
7 degree 11 degree 12 degree 34mm 36mm 38mm 40mm Chisel Drill Bit for Hex22 Shank Rod
7 degree 11 degree 12 degree 34mm 36mm 38mm 40mm Chisel Drill Bit for Hex22 Shank Rod
7 degree 11 degree 12 degree 34mm 36mm 38mm 40mm Chisel Drill Bit for Hex22 Shank Rod
Specifications
Brand Name :
MIROC
Model Number :
Tapered Chisel bit
Certification :
SGS
Place of Origin :
China
MOQ :
50pcs
Price :
negotiation
Payment Terms :
T/T, L/C, D/A, D/P, Western Union
Supply Ability :
30000pieces per month
Delivery Time :
15-20days
Packaging Details :
Wooden box
Color :
Yellow/Black/Green
Material :
Tungsten Carbide buttons
Application :
used for hex22 shank rod
Description

7 degree 11 degree 12 degree 34mm 36mm 38mm 40mm Chisel Drill Bit for Hex22 Shank Rod

Our drill bits are made with high quality alloy steel bar and tungsten carbides, through heat treatment.

Caracteristique:

(1)Button bit taper angle: 4°,4°46″,6°,7°,11°,12°

(2)Models:chisel bit/cross bit/button bit

(3)Diam:20-45 mm

(4)Button bit shape:spherical/parabolic

(5)Socket inside diameter:15/19/22/25(mm)

Application

Widely used in drilling holes with depth less than 5 meters and diameter ranged in 20-45 mm by light-duty rock drill, like Y6.

What can you get from KSQ?

1. Good service for the products purchased
2. Good quality control of products produced
3. Reasonable prices for the products offered
4. Best advices based on the experience and knowledge of well know what to do and how to do

Product Codes System:

Tapered Button Bits:


BS432-7D-(22)(23)
BS = Button Bit, Short Skirt
4 = Number of Tungsten Carbide Inserts
32 = Bit Diameter in mm
---
7D = 7 Degrees Taper
---
(22) (23) = Bit Inside Diameter in mm, specific for Tapered Rod Diameter

Tapered Chisel Bits:


C26-7D-(22)(23)
C = Chisel Bit
26 = Bit Diameter in mm
---
7D = 7 Degrees Taper
---
(22) (23) = Bit Inside Diameter in mm, specific for Tapered Rod
Diameter

Tapered Cross Type Bits:


CR(S)45-H25
CR = Cross Type Bit, Tungsten Carbide Inserts
CRS = Cross Type Bit, Steel Inserts
64 = Bit Diameter in mm
---
H25 = Thread System
Tapered Drill Rods:
H22-7D-600
H22 = Hex 22 mm Tapered Rod
---
7D = 7 Degrees Taper
---
600 = Effective Drill Rod Length in mm

Product Description

Tapered button bit to drill quarry granite rock

Bit diameter: 32mm to 42mm

Body height: 50mm, 55mm,60mm

Taper/Grade: 6 degree, 7 degree, 11 dregree, 12 degree

Shank Diameter: for Hex22 tapered rod

Description

Diameter

Length

Water hole

Taper degree: 4°, 6°, 7°, 11°, 12°
Socket inside d=15,19,22,25mm

7 degree 11 degree 12 degree 34mm 36mm 38mm 40mm Chisel Drill Bit for Hex22 Shank Rod

mm

mm

2

20

65

2

23

65

2

25

69

2

28

60

2

30

55 88

2

32

55 64 71 80

2

34

71 80

2

36

74

2

38

74

2

40

74

2

42

74

2

45

74

2

Related productions

Taper button bit - For 22 mm (7⁄8") hex. Rod

7 degree 11 degree 12 degree 34mm 36mm 38mm 40mm Chisel Drill Bit for Hex22 Shank Rod

Bit Diameter

mm

32

33

34

35

36

38

40

42

inch

1 1/4

1 2/7

1 1/3

1 3/8

1 3/7

1 1/2

1 4/7

1 2/3

7 degree 11 degree 12 degree 34mm 36mm 38mm 40mm Chisel Drill Bit for Hex22 Shank Rod

Tungsten Carbide Button Number

4, 6, 7

Taper/Grade

6,7,11,12 degree

7 degree 11 degree 12 degree 34mm 36mm 38mm 40mm Chisel Drill Bit for Hex22 Shank Rod

7 degree 11 degree 12 degree 34mm 36mm 38mm 40mm Chisel Drill Bit for Hex22 Shank Rod

drill bit | broca | broca | foret | Bohrer | matkap ucu | punta da trapano | boorpunt | jesie | boret drill bit | broca | broca | foret | Bohrer | matkap ucu | punta da trapano | boorpunt | jesie | boret tapered tungsten carbides knock off drill bit

Wooden box Package:

7 degree 11 degree 12 degree 34mm 36mm 38mm 40mm Chisel Drill Bit for Hex22 Shank Rod

Other products related:

(1) Integral Drill Rod– chisel bit integral rod, plug hole integral drill steel,

Shank H19 x 108mm and H22 108mm.


(2) Tapered Rock Drill Tools - chisel bit, cross bit, button bit, drill rod of taper 7, 11, 12 degree


(3) Threaded Rock Drill Tools - button bit, retrac button bit, drop center button bit, dome bit, reaming bit,extension rod, MF-Rod, Hex rod, coupling sleeve, crossover coupling of thread R25, R28, R32, R38, T38, T45, T51, ST58, ST68.


(4) Shank Adapters (Striking Bars) - equivalent to Atlas Copco, , Furukawa, Gardner Genver, Ingersoll Rand etc.


(5) Down-the-hole (DTH) Bits & Hammers - 3'', 4'', 5'', 6'', 8'', 10", 12" hammers and DTH button bits (diameter 80mm - 445mm)
