Forging R25 Thread Button Bits Rock Drilling Tungsten Carbide Drill Tools
Forging R25 Thread Button Bits Rock Drilling Tungsten Carbide Drill Tools
Forging R25 Thread Button Bits Rock Drilling Tungsten Carbide Drill Tools
Forging R25 Thread Button Bits Rock Drilling Tungsten Carbide Drill Tools
Forging R25 Thread Button Bits Rock Drilling Tungsten Carbide Drill Tools
Forging R25 Thread Button Bits Rock Drilling Tungsten Carbide Drill Tools
Forging R25 Thread Button Bits Rock Drilling Tungsten Carbide Drill Tools
Forging R25 Thread Button Bits Rock Drilling Tungsten Carbide Drill Tools
Specifications
Brand Name :
MIROC
Model Number :
Thread Button Bits
Certification :
ISO9001:2000
Place of Origin :
Shangdong,China
MOQ :
5 Pieces
Price :
negotiation
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
30000pcs per month
Delivery Time :
10-22days
Packaging Details :
Carton Box or Wooden Box
Type :
Thread Button Bits
Material :
Alloy steel bar and tungsten carbide
Color :
Green
Processing Type :
Forging
Button bit shape :
Ballistic
Face shape :
Flat face
Body shape :
Normal Body
Thread :
R25 R32
Description

Forging R25 R32 Thread Button Rock Drill Tools Tungsten Carbide Drill Bits

Button bit is well known for its high wear resistance on medium-hard to hard abrasive rock formations (between 200 Mpa to 260 Mpa compressive strength). Featuring spherical tungsten carbide inserts that is known to have strong configuration against carbide fracture.

• Widely used drifting and tunneling
• Bit face design is ideal for medium-hard to hard abrasive rock

Button bit and Insert types
Spherical Button Characteristics:
1. Universal button
2. Good wear resistance
3. Best suited for hard ground
4. 27000-48000PSI(180 to 320Mpa)
5. Suited for abrasive to very abrasive drilling conditions


Ballistic Button Characteristics:
1. Fast Penetration
2. Best suited for soft rock
3. 10000-20000PSI(70 to 140Mpa)
4. Suited for non-abrasive drilling conditions

Applications of rock drilling tools

• Underground mining
• Tunneling,quarrying

Competitive Advantage

• High grade tungsten carbide inserts
• Bit bodies manufactured from high grade steel and processed using state-of-the-art CNC machinery and heat treatment

Product Name:

different rock hardness drilling button bit

Description:

For different rock hardness mining,tunneling,quarrying button bit

Button bit Made with high quality of best quality alloy steel bar and tungsten carbide, through heat treatment.

Material:

Alloy steel bar and tungsten carbide bit

MOQ:

trial order 1-5pcs

Body Type

Normal type and retract type

Thread type

R25,R28,R32,R38,T38,T45,T51,ST58,ST68

Diameter

32mm-152mm

Button bit shape

Spherical and Ballistic

Face shape

Flat shape and Drop-center shape

Forging R25 Thread Button Bits Rock Drilling Tungsten Carbide Drill ToolsForging R25 Thread Button Bits Rock Drilling Tungsten Carbide Drill Tools
