Single Row Nup Cylindrical Roller Bearing With Cage NUP303E Radial Cylindrical Roller Bearings
Single Row Nup Cylindrical Roller Bearing With Cage NUP303E Radial Cylindrical Roller Bearings
Specifications
Brand Name :
MOUETTE
Model Number :
NUP303E, NUP304E, NUP305E, NUP306E, NUP307E, NUP308E, NUP309E, NUP310E, NUP311E, NUP312E, NUP313E, NUP314E, NUP315E, NUP316E, NUP317E, NUP318E, NUP319E, NUP320E, NUP322E, NUP324E, NUP326E, NUP328E
Certification :
ISO/TS 16949:2009, ISO 9001:2008
Place of Origin :
China
MOQ :
100
Price :
USD2 per Piece (Inquired for details)
Payment Terms :
L/C, T/T, D/A, Western Union, Paypal
Supply Ability :
500,000 Pieces per Month.
Delivery Time :
3-50 working days.(Huge Quantity Stocks Available))
Packaging Details :
Plastic bags, Cartons and European Standard Plywood Case.
Name :
Single Row Cylindrical Roller Bearing
Design E :
Increased Capacity Design
Cage Material :
Steel / Solid Window Cage made from PA66
Bearing Material :
Bearing Quality Steel 100Cr6, GCr15, AISI 52100
Measurement System :
Metric series
Sealing :
Open
Tolerance class :
Normal / Customized
Number of rolling element rows :
Single-row design
Other Featurs :
with cage, single row, locating bearing, 2 ribs on outer ring, 1 rib on inner ring, rib washer internal
Radial internal clearance :
CN
Description

Single Row Cylindrical Roller Bearing With Cage Removable Inner Ring NUP303E

Type NUP Series, Cylindrical Roller Bearing, Single Row, Straight Bore, Removable Inner Ring, Two Piece, High Capacity, Normal Clearance, Metric size

About this item

  • Cylindrical roller bearing with a removable inner ring suitable for high radial loads
  • CN (normal) radial clearance for applications where thermal expansion is not a factor
  • Single row roller bearing for high radial loads with low friction
  • Removable inner ring in open bearing allows for lubrication in place
  • Metric unit measurements for industry consistency

Single Row Cylindrical Roller Bearing With Cage Removable Inner Ring NUP Series Details:

Bearing Code Dimensions Mass Basic Load Ratings Limiting Speed
d D B rsmin D1 Fw, Ew dynamic static
Cr Cor
mm kg KN rpm
NUP303E 17 47 14 1 37 24.2 0.127 25.5 21.2 16000
NUP304E 20 52 15 1.1 42.4 27.5 0.16 31.5 27 14000
NUP305E 25 62 17 1.1 50.7 34 0.256 41.5 37.5 12000
NUP306E 30 72 19 1.1 58.9 40.5 0.385 51 48 10000
NUP307E 35 80 21 1.5 66.3 46.2 0.506 64 63 9000
NUP308E 40 90 23 1.5 75.6 52 0.688 81.5 78 7500
NUP309E 45 100 25 1.5 83.5 58.5 0.934 98 100 6700
NUP310E 50 110 27 2 91.2 65 1.21 110 114 6300
NUP311E 55 120 29 2 101 70.5 1.54 134 140 5600
NUP312E 60 130 31 2.1 110 77 1.93 150 156 5000
NUP313E 65 140 33 2.1 119 82.5 2.37 180 190 4800
NUP314E 70 150 35 2.1 127 89 2.89 204 220 4500
NUP315E 75 160 37 2.1 136 95 　 240 265 4000
NUP316E 80 170 39 2.1 144 101 4.11 255 275 3800
NUP317E 85 180 41 3 153 108 4.8 270 300 3600
NUP318E 90 190 43 3 162 113.5 5.59 315 345 3400
NUP319E 95 200 45 3 170 121.5 6.55 335 380 3400
NUP320E 100 215 47 3 182 127.5 7.96 380 425 5000
NUP322E 110 240 50 3 201 143 10.7 440 510 4800
NUP324E 120 260 55 3 219 154 13.8 520 600 2800
NUP326E 130 280 58 4 236 167 17 610 720 2600
NUP328E 140 300 62 4 252 180 20.8 670 800 2400

Single Row Nup Cylindrical Roller Bearing With Cage NUP303E Radial Cylindrical Roller Bearings

Single Row Nup Cylindrical Roller Bearing With Cage NUP303E Radial Cylindrical Roller Bearings

Single Row Nup Cylindrical Roller Bearing With Cage NUP303E Radial Cylindrical Roller Bearings

Single Row Nup Cylindrical Roller Bearing With Cage NUP303E Radial Cylindrical Roller Bearings

Single Row Nup Cylindrical Roller Bearing With Cage NUP303E Radial Cylindrical Roller Bearings
