Specifications
Brand Name :
MOUETTE
Model Number :
NJ202ECP, NJ203E, NJ204E, NJ205E, NJ206E, NJ207E, NJ208E, NJ209E, NJ210E, NJ211E, NJ212E, NJ213E, NJ214E, NJ215E, NJ216E, NJ217E, NJ218E, NJ219E, NJ220E, NJ221E, NJ222E, NJ226E, NJ228E, NJ230E, NJ232E, NJ234E, NJ236E, NJ238E, NJ240E, NJ244E, NJ248E, NJ252E
Certification :
ISO/TS 16949:2009, ISO 9001:2008
Place of Origin :
China
MOQ :
200
Price :
USD5 per Piece
Payment Terms :
L/C, T/T, D/A, Western Union, Paypal
Supply Ability :
500,000 Pieces per Month.
Delivery Time :
3-45 working days.(Huge Quantity Stocks Available))
Packaging Details :
Plastic bags, Cartons and European Standard Plywood Case.
Name :
Cylindrical Roller Bearings Single Row
Bearing Type :
NJ type
Bore Type :
Straight
Number of Rows :
1
Ring Separation :
Separable Outer Ring
Flanges :
(2) Outer Ring, (1) Inner Ring
Design :
"E" Design - Increased Capacity Design
Radial Internal Play :
Normal Internal Play / Customized
Cage Material :
Steel/ Solid Window Cage made from PA66/ Machined Brass / Customized
Operating Temperature Range :
-30 to +120 °C
Description

Caged Cylindrical Roller Bearing Single Row With Removable Inner Ring NJ208E

Cylindrical roller bearing, with cage, single row, semi-locating bearing, 2 ribs on outer ring, 1 rib on inner ring, type NJ

Overview:

  • Single row cylindrical roller bearings with cage are units comprising solid inner and outer rings together with cylindrical roller and cage assemblies
  • Outer rings have rigid ribs on both sides or are without ribs, the inner rings have one or two rigid ribs or are designed without ribs
  • Cage prevents the cylindrical rollers coming into contact with each other during rolling
  • Cage Material: Steel/ Solid Window Cage made from PA66/ Machined Brass / Customized, all are available
  • NJ: Two outer flanges, one inner flange

Caged Cylindrical Roller Bearing Single Row With Removable Inner Ring Specifications:

Bearing Code Dimensions Mass Basic Load Ratings Limiting Speed
d D B rsmin d1 D1 Fw, Ew dynamic static
Cr Cor
mm kg KN 　 rpm
NJ202ECP 15 35 11 0.6 — 27.9 19.3 0.049 12.7 10.4 22000
NJ203E 17 40 12 0.6 — 32.4 22.1 0.07 17.6 14.6 18000
NJ204E 20 47 14 1 — 38.8 26.5 0.117 27.5 24.5 16000
NJ205E 25 52 15 1 — 43.8 31.5 0.14 29 27.5 15000
NJ206E 30 62 16 1 — 52.5 37.5 0.213 39 37.5 12000
NJ207E 35 72 17 1.1 — 60.7 44 0.309 50 50 10000
NJ208E 40 80 18 1.1 — 67.9 49.5 0.389 53 53 9000
NJ209E 45 85 19 1.1 — 73 54.5 0.445 61 63 8500
NJ210E 50 90 20 1.1 — 78 59.5 0.503 64 68 8000
NJ211E 55 100 21 1.5 — 86.3 66 0.679 83 95 7000
NJ212E 60 110 22 1.5 — 95.7 72 0.845 95 1.4 6300
NJ213E 65 120 23 1.5 — 104 78.5 1.06 108 120 6000
NJ214E 70 125 24 1.5 — 109 83.5 1.18 120 137 5300
NJ215E 75 130 25 1.5 — 114 88.5 1.3 132 156 5300
NJ216E 80 140 26 2 — 123 95.3 1.58 140 170 4800
NJ217E 85 150 28 2 — 131 100.5 1.95 163 193 4500
NJ218E 90 160 30 2 — 140 107 2.41 183 216 4300
NJ219E 95 170 32 2.1 — 149 112.5 2.94 220 265 3800
NJ220E 100 180 34 2.1 — 157 119 3.55 250 3.5 3800
NJ221E 105 190 36 2.1 — 164 125 4.17 260 320 5600
NJ222E 110 200 38 2.1 — 174 132.5 4.93 290 365 3400
NJ224E 120 215 40 2.1 — 188 143.5 5.91 335 415 3200
NJ226E 130 230 40 3 — 202 153.5 6.63 360 450 3000
NJ228E 140 250 42 3 — 217 169 9.46 390 510 4800
NJ230E 150 270 45 3 — 234 182 11.9 440 585 4500
NJ232E 160 290 48 3 — 250 195 14.8 500 670 4300
NJ234E 170 310 52 4 — 268 207 18.4 585 780 3600
NJ236E 180 320 52 4 — 279 217 16.7 610 830 3600
NJ238E 190 340 55 4 — 295 230 23.2 680 930 3200
NJ240E 200 360 58 4 — 312 243 31 750 1040 3000
NJ244E 220 400 65 4 — 344 268 38.7 950 1320 2800
NJ248E 240 440 72 4 — 365 295 52.5 1140 1600 2600
NJ252E 260 480 80 5 — 397 320 70 1340 1900 2400
NJ256E 280 500 80 5 — 417 340 73 1400 2000 2200
NJ1060M1 300 460 74 4 — 402 340 47 900 1430 2400
NJ1064M1 320 480 74 4 — 422 360 49 915 1500 2400
NJ1076M1 380 560 82 5 — 495 425 73 1180 2000 2000
