Warehouse Sectional Overhead Door Vertical Lift 12m Width 35m/s Wind Resistant
Warehouse Sectional Overhead Door Vertical Lift 12m Width 35m/s Wind Resistant
Warehouse Sectional Overhead Door Vertical Lift 12m Width 35m/s Wind Resistant
Warehouse Sectional Overhead Door Vertical Lift 12m Width 35m/s Wind Resistant
Warehouse Sectional Overhead Door Vertical Lift 12m Width 35m/s Wind Resistant
Warehouse Sectional Overhead Door Vertical Lift 12m Width 35m/s Wind Resistant
Specifications
Brand Name :
YUOU
Model Number :
Yuou-Sectional
Certification :
ISO9001
Place of Origin :
Henan, China
MOQ :
1 piece
Price :
$500.00 - $1000.00/Piece
Payment Terms :
D/A, L/C, , T/T, Western Union, MoneyGram
Supply Ability :
1000 Piece/Pieces per Month
Delivery Time :
7-10 work days
Packaging Details :
Standard export wooden case
Product name :
Industrial Automatic Vertical Lift Industrial Sectional Overhead Door For Warehouse
After-sale Service :
Online technical support, Onsite Training, Onsite Inspection, Return and Replacement, Other
Max. door size :
12(W)x8(H)m
Opening speed :
20-40cm/s
Lifting method :
Standard, high, vertical
Door panel :
Steel plate + PU foam
Surface treatment :
Power coated
Control mode :
Electric or manual
Color :
Silver or customized
Motor :
Chinese top brand
Hinges :
Industrial class
Application :
Warehouse, workshop
Description

Industrial Automatic Vertical Lift Industrial Sectional Overhead Door For Warehouse

Technical Data
Lifting method Standard lift, high lift, vertical lift
Configuration Clear window and pedestrian door
Opening and closing speed 20-40cm/s
Door panel Steel plate + PU foam
Components Motor, airbag, spring brake device, cable break device, pulleys, control box, brackets
Wind resistance 28-35m/s (Class 10-12)
Operation method Control box, remote control
Guide rail Galvanized steel
Operation counts Max 100times /24 hours
K value 1.5W/M2.K
Thermal conducivity ≦ 0.033W/M.K

1. Installation environment

Installation site: outside or inside room

Wind resistance: 30m/s , Class 11

2. Excellent insulation performance

The total thickness of the door panel is 40 mm, density of PU foam is 48kg/m3
It has excellent thermal insulation performance

3. Automatic/ manual dual operation mode

When power is off or faulty, it can be turned on or off by manually operating the chain. The balanced torsion spring system conteracts most of the tension at the opening. It can be opened with a little force by hand ( 180N) or easily opened with a hand chain.

4. Balance spring

Spring brake device :anti-broken

Service life:100 thousand opening and closing

Driving force:140N

Chosen according to door size, weight and lifting pattern.

5. Accident-dropping safety device

Equipped with dropping avoiding steel cord at the bottom, to secure the accident dropping within 5cm

6. Guide rail

Special design three angle wheel brace secure smooth rolling of wheel

Noise level ≤60db

7. Manual chain device

Equip with manual chain in case power failure

8. Rail strengthening plate

2.0mm galvanized steel plate

9. Security performance

Bottom sensor: it makes the door body lift back when touching something during closing and stops the movement during opening.

Sectional door advantages

Industrial sectional door, as the best choice of the outdoor of the modern architecture, enjoys the perfect durability and sealing, the elegant aprrearance, the simple operating system and the spring balanced system, which is used durably and cleaned easily with the special designing door panel.
