Steel 12x12 Fire Rated Roll Up Door 66kp Windproof galvanized
Steel 12x12 Fire Rated Roll Up Door 66kp Windproof galvanized
Specifications
Brand Name :
YUOU
Model Number :
Yuou-Steel fire roller shutter
Certification :
ISO9001
Place of Origin :
Henan, China
MOQ :
1 piece
Price :
$200.00 - $1000.00/Piece
Payment Terms :
D/A, L/C, , T/T, Western Union, MoneyGram
Supply Ability :
1000 Piece/Pieces per Month
Delivery Time :
7-10 work days
Packaging Details :
Standard export wooden case
Product name :
Fire Rated Rolling Up Steel Fire Roller Shutter Door For Factory
After-sale Service :
Online technical support, Onsite Training, Onsite Inspection, Return and Replacement, Other
Shutter Slat :
Galvanized steel
Slat thickness :
double layer 0.8mm
Filling material :
Aluminum silicate wool
Max. door size :
12m*12m
Fire rating :
3 hours
Wind resistance :
8-12level (24.5-32.6m/s)
Surface finishing :
Finished
Hood cover box :
1.0mm galvanized steel
Warranty :
1 year
HS code :
85308000
Description

Fire Rated Rolling Up Steel Fire Roller Shutter Door For Factory

Technical Data
Model Fire rated Stell Roller shutter door
Material Double skin 0.8mm thickness
Inside filling Aluminum silicate wool
Max. door size width * height 8000mm*10000mm
Opening and closing speed 5-7.5m/min
Motor Chinese top brand
Fire rated time ≥3 hours
Surface finishing Finished
Wind resistance 50-66kp(30m/s)
Operation
Certificate Chinese CCC
Warranty 1 year

Standard:

Comply with China National standard GB14102-2005 Fire Roller Shutter Door

Door slats:

A. Double skin 0.8mm thickness
B. Aluminum silicate wool is filled in the middle.

Guide rail:

2.0mm thick galvanized steel. Surface is galvanized

Motor:

(Fireproof) Industrial grade motor specially used for Roller Shutter Door. The best brand of motor in China Power supply:380V/50HZ,Power: 0.3-1.5KW. Wore temperature:-25 ℃-55℃. Low noise.

Control panel:

Fireproof control box specially used for Roller Shutter Door. The best brand of control panel in China ALAND. Through it , user can control the door manually for UP,DOWN,STOP. And it can also be connected with Fire Control Center, or with smoke sensor or temperature sensor, to control the door movement automatically in case of fire accidents.

Hood cover box:

1mm power coated galvanized steel

Optional operation method

□ Smoke sensor □ Temperature sensor 　□ Release device

Steel 12x12 Fire Rated Roll Up Door 66kp Windproof galvanized
