Mirror Finish AISI 316L Stainless Steel U Channels 6m ASTM A276
Mirror Finish AISI 316L Stainless Steel U Channels 6m ASTM A276
Mirror Finish AISI 316L Stainless Steel U Channels 6m ASTM A276
Mirror Finish AISI 316L Stainless Steel U Channels 6m ASTM A276
Mirror Finish AISI 316L Stainless Steel U Channels 6m ASTM A276
Mirror Finish AISI 316L Stainless Steel U Channels 6m ASTM A276
Specifications
Brand Name :
TISCO
Model Number :
Stainless Steel Channel Bar
Certification :
SGS,BV
Place of Origin :
China(mainland)
MOQ :
1 Ton
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram, D/P
Supply Ability :
5000 Ton/Tons per Month
Delivery Time :
10-15 days after deposit
Packaging Details :
in bundle, plastic bags, thin film, wooden pallet, standard seaworthy export packing or as customer demands
Material :
Stainless Steel
Standard :
ASTM GB EN
Application :
Steel Structure Building
Technique :
Hot Rolled
Processing Service :
Bending, Welding, Punching, Decoiling, Cutting
Size :
40*20*3 – 200*100*12mm
Length :
6m or Customers' Requirements
Shape :
U Channel
Finish :
NO.1 ,MILL Finish
Other Grade :
201 202 304 304L 316L 2205 904L Duplex ,Q235
Description

Mirror Finish ASTM A276 AISI 304 316L Stainless Steel U Channel Bar SS Channel Bar

Product Specifications:

Stainless steel channel offers a wide variety of features and come in a variety of dimensions at Stainless Shapes. Stainless steel channel is shaped using a vertical web with top and bottom flanges at a 90-degree angle to the web and inside radius corners to increase the channel’s strength. Channel can be hot-rolled, extruded, or laser-fused. The following benefits and features make stainless steel channel a great choice for a wide range of industries and applications.

  • Corrosion resistance makes channel an ideal product for chemical, petrochemical, and waste treatment applications.
  • Low cost
  • High-temperature resistance
  • Surface finish is ideal for food, medical and pharmaceutical manufacturing applications
  • Easily machinable
  • Weld to exact tolerances

ITEM Stainless Steel Channels
Size 50*37mm*4.5-400*104*14.5mm or customized
Length 6m,9m,12m or as required
Surface Pickling, hot rolled, annealed
Grade

201.202.301.302.304.304L.310S.316.316L.321.430.430A.309S.2205.2507.2520.430.410.

440.904Lect. Or Customized
Standard GB, AISI, ASTM, ASME, EN, BS, DIN, JIS
Trade Term FOB CIF CFR CNF EXWORK
Application Architecture and engineer structure ,industry ,etc
Package Standard export sea-worthy packing or customized
Delivery 7-15 days after deposit
Payment TT/LC
Sample Offer the sample for free charge but do not pay the cost of freight

Product Surface Treatment:

Finish Thickness Characteristics Applications
No. 1 3.0mm~50.0mm Finished by hot-rolling Chemical industry
No. 2B 0.3mm~6.0mm Finished by heat treatment General Application
No. BA (Bright Annealed) 0.5mm~2.0mm Bright heat treatment Kitchen utensil
No. 4 0.4mm~3.0mm Polishing Milk & Food processing
HL(Hair Line) 0.4mm~3.0mm Finished by continuous heating Architectural pu

Size Of Our Staineless Steel Channel Bar:

Sizes(mm)
H×B		 Thickness (mm)
3 4 5 6 7 8 9 10 12
40×20 1.79
50×25 2.27
60×30 2.74 3.56 4.37 5.12
70×35 3.23 4.21 5.17

6.08
80×40 3.71 4.84 5.96

7.03
90×45 4.25 5.55 6.83 8.05
100×50 4.73 6.18 7.62 8.98 10.3 11.7 13.0 41.2
120×60 9.20 10.9 12.6 14.2
130×65 10.1 11.9 13.8 15.5 17.3 19.1
140×70 12.9 14.9

16.8

 18.8 20.7
150×75 13.9 16.0 18.1 20.2 22.2 26.3
160×80 14.8 17.1 19.3 21.6 23.8 28.1
180×90 16.7 19.4 22.0 24.5 27.0 32.0
200×100 18.6 21.6 24.5 27.4 30.2

35.8

Chemical Composition:

Grade C Si Mn P S Ni Cr Mo
201 ≤0.15 ≤0.75 5.5-7.5 ≤0.06 ≤ 0.03 3.5-5.5 16.0-18.0 -
301 ≤0.15 ≤1.0 ≤2.0 ≤0.045 ≤ 0.03 6.0-8.0 16.0-18.0 -
304 ≤0.08 ≤1.0 ≤2.0 ≤0.045 ≤ 0.03 8.0-10.5 18.0-20.0 -
304L ≤0.03 ≤1.0 ≤2.0 ≤0.035 ≤ 0.03 9.0-13.0 18.0-20.0 -
316 ≤0.08 ≤1.0 ≤2.0 ≤0.045 ≤ 0.03 10.0-14.0 16.0-18.0 2.0-3.0
316L ≤0.03 ≤1.0 ≤2.0 ≤0.045 ≤ 0.03 12.0-15.0 16 .0-1 8.0 2.0-3.0
321 ≤0.08 ≤1.0 ≤2.0 ≤0.035 ≤ 0.03 9.013 17.0-1 9.0 -
410 ≤0.15 ≤1.0 ≤1.0 ≤0.035 ≤ 0.03 - 11.5-13.5 -
430 ≤0.12 ≤0.75 ≤1.0 ≤0.040 ≤ 0.03 ≤0.60 16.0-18.0 -

Advantage of Our Service:


1. High quality.
2. Reasonable price.
3. Convenient in construction and save much time and labor.
4. light, good quality and competitive price.
5. length of the product can be manufactured according to customer’s requirements.
6. Quality garantee after selling.

FAQ:

Q1. What are your company's main products ?

A1: Our main products are stainless steel plate/sheet, coil, round/square pipe, bar, channel, etc.

Q2. How do you control quality ?

A2: Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS,Alibaba Verified.

Q3: What is the terms of packing?

A3: generally, we pack our goods in bundles or coils with rods or belts, we could also pack the goods as the customers requirement.

Q4:What is your delivery time?

A4: For stocks, we could transport the goods to loading port within 7 days after we received your deposit

For production period, it usually takes about 15 days-30 days after receiving the deposit.

Q5. What are the advantages of your company ?

A35: We have many professionals, technical personnel, more competitive prices and best after-dales service than other stainless steel companies.

Q6. How many coutries you already exported ?

A6: Exported to more than 50 countries mainly from America, Russia, UK, Kuwait, Egypt, Turkey, Jordan,India, etc.

Q7. Can you provide sample ?

A7: We can provide the samll samples in stock for free, as long as you contact us.

Customized samples will take about 5-7days.
