Hot Rolled ASTM A479 201 Stainless Steel H Channel WIth Pickled Finish
Hot Rolled ASTM A479 201 Stainless Steel H Channel WIth Pickled Finish
Hot Rolled ASTM A479 201 Stainless Steel H Channel WIth Pickled Finish
Hot Rolled ASTM A479 201 Stainless Steel H Channel WIth Pickled Finish
Hot Rolled ASTM A479 201 Stainless Steel H Channel WIth Pickled Finish
Hot Rolled ASTM A479 201 Stainless Steel H Channel WIth Pickled Finish
Specifications
Brand Name :
TISCO
Model Number :
Stainless Steel Channel Bar
Certification :
SGS,BV
Place of Origin :
China(mainland)
MOQ :
1 Ton
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram, D/P
Supply Ability :
5000 Ton/Tons per Month
Delivery Time :
10-15 days after deposit
Packaging Details :
in bundle, plastic bags, thin film, wooden pallet, standard seaworthy export packing or as customer demands
Material :
Stainless Steel
Standard :
ASTM GB EN
Application :
Steel Structure Building
Technique :
Hot Rolled
Processing Service :
Bending, Welding, Punching, Decoiling, Cutting
Size :
40*20*3 – 200*100*12mm
Length :
6m or Customers' Requirements
Shape :
U Channel
Finish :
NO.1 ,MILL Finish
Other Grade :
201 202 304 304L 316L 2205 904L Duplex ,Q235
Description

Hot Rolled ASTM A479 201 Stainless Steel H U Channel Bar Pickled Finished

Product Specifications:

  • 1). Material: 201, 202, 304, 316, 316L, 310 ect
  • 2). Size: All the dimension are all according to your requirements
  • 3). Useage: Construction, industry
  • 4). Standard: GB/T 1220-2007, GB/T707-1988, ASTM A276, A314, A479, A484, A564, A582, etc.
  • 5). Finish: Pickling, Sand-blasting, hairline, Polish, Mirror Polish, Milling, Smooth-turning, Peeling, etc.
  • 6). Payment term: Pay 30% down payment then the lasted 70%should be pay before delivery
  • 7). Delivery time: About 15 working days or depend on the quantity
  • 8). Packing: Export standard pckage or as your requirements
  • 9). Min. Order: One ton

Size Of Our Staineless Steel Channel Bar:

Sizes(mm)
H×B		 Thickness (mm)
3 4 5 6 7 8 9 10 12
40×20 1.79
50×25 2.27
60×30 2.74 3.56 4.37 5.12
70×35 3.23 4.21 5.17

6.08
80×40 3.71 4.84 5.96

7.03
90×45 4.25 5.55 6.83 8.05
100×50 4.73 6.18 7.62 8.98 10.3 11.7 13.0 41.2
120×60 9.20 10.9 12.6 14.2
130×65 10.1 11.9 13.8 15.5 17.3 19.1
140×70 12.9 14.9

16.8

 18.8 20.7
150×75 13.9 16.0 18.1 20.2 22.2 26.3
160×80 14.8 17.1 19.3 21.6 23.8 28.1
180×90 16.7 19.4 22.0 24.5 27.0 32.0
200×100 18.6 21.6 24.5 27.4 30.2

35.8


Chemical Composition:

GRADE

AISI

C

(MAX)

Mn

(MAX)

P

(MAX)

S

(MAX)

Si

(MAX)

 Cr Ni Mo
301 0.15 2.0 0.045 0.040 1.0 16-18 6--8 ---
303 0.15 2.0 0.045 ----- 1.0 17-19 8 -10 ---
304 0.08 2.0 0.045 0.030 1.0 18-20 8 -10 ---
304 L 0.030 2.0 0.045 0.030 1.0 18-20 8 -10 ---
316 0.08 2.0 0.045 0.030 1.0 16-18 10 -14 2-3
316L 0.030 2.0 0.045 0.030 1.0 16-18 10 -14 2-3
410 0.15 1.0 0.040 0.030 1.0 11.5-13.5 0.60 ---
430 0.12 1.0 0.04 0.03 1.00 16-18 ---- --
310 0.25 2.0 0.045 0.030 1.50 24-26

19

22
310S 0.08 2.0 0.045 0.030 1.50 24-26

19

22

Product Surface:

Finish Thickness Characteristics Applications
No. 1 3.0mm~50.0mm Finished by hot-rolling Chemical industry
No. 2B 0.3mm~6.0mm Finished by heat treatment General Application
No. BA (Bright Annealed) 0.5mm~2.0mm Bright heat treatment Kitchen utensil
No. 4 0.4mm~3.0mm Polishing Milk & Food processing
HL(Hair Line) 0.4mm~3.0mm Finished by continuous heating Architectural pu

Advantage of Stainless Steel Channel Bar:


1. High quality.
2. Reasonable price.
3. Convenient in construction and save much time and labor.
4. light, good quality and competitive price.
5. length of the product can be manufactured according to customer’s requirements.
6. High mechanical strength, back to back C channel, increase the intensity.

Application:

Our products is widely used in hotels, airport lounges, car transport station, playground ,Shopping malls, factories, office buildings, old building renovation, interior decoration of the building, roof and other places set.
We can supply you the samples according to your requirements,all the designs and sizes can be customized and we have quality guarantee with our best after- sales services.

FAQ:

Q1. What are your company's main products ?

A1: Our main products are stainless steel plate/sheet, coil, round/square pipe, bar, channel, etc.

Q2. How do you control quality ?

A2: Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS,Alibaba Verified.

Q3: What is the terms of packing?

A3: generally, we pack our goods in bundles or coils with rods or belts, we could also pack the goods as the customers requirement.

Q4:What is your delivery time?

A4: For stocks, we could transport the goods to loading port within 7 days after we received your deposit

For production period, it usually takes about 15 days-30 days after receiving the deposit.

Q5. What are the advantages of your company ?

A35: We have many professionals, technical personnel, more competitive prices and best after-dales service than other stainless steel companies.

Q6. How many coutries you already exported ?

A6: Exported to more than 50 countries mainly from America, Russia, UK, Kuwait, Egypt, Turkey, Jordan,India, etc.

Q7. Can you provide sample ?

A7: We can provide the samll samples in stock for free, as long as you contact us.

Customized samples will take about 5-7days.
