Stainless Steel Plate 0.7mm BA Surface 304 430 201 316 316L Stainless Steel Sheet
The corrosion resistance of stainless steel plate mainly depends on its alloy composition (chromium,
nickel, titanium, silicon, aluminum, manganese, etc.) and internal organizational structure, the main
role is chromium element. Chromium has high chemical stability, can form a passivation film on the
surface of steel, so that the metal is isolated from the outside world, protect the steel plate from
oxidation, increase the corrosion resistance of the steel plate. After the passivation film is destroyed,
the corrosion resistance decreases.
AISI TYPE | C | Si | Mn | P | S | Ni | Cr. | Mo |
Austentic St. Steel | ||||||||
303 | 0.15 | 1.00 | 2.00 | 0.20 | 0.15 | 8.00 10.00 | 17.00 19.00 | |
304 | 0.06 | 1.00 | 20.00 | 0.045 | 0.030 | 8.00 10.00 | 18.00 20.00 | |
304L | 0.03 | 1.00 | 2.00 | 0.045 | 0.030 | 11 | 18 | |
316 | 0.07 | 1.00 | 2.00 | 0.045 | 0.030 | 11 | 18 | 2.00 3.00 |
318L | 0.03 | 1.00 | 2.00 | 0.045 | 0.030 | 13 | 18 | 2.00 3.00 |
317 | 0.06 | 1.00 | 2.00 | 0.045 | 0.030 | 13 | 18 | 3.00 4.00 |
317L | 0.03 | 0.50 | 1.75 | 0.045 | 0.030 | 14 | 19 | 3.00 3.00 |
321 | 0.08 | 1.00 | 2.00 | 0.45 | 0.030 | 11 | 18 | |
325 | 0.25 | 2.00 | 0.60 | 0.045 | 0.030 | 19.00 23.00 | 10 | |
347 | 0.08 | 1.00 | 2.00 | 0.045 | 0.030 | 11 | 15 | |
Heat Resisting Steel | ||||||||
309 | 0.20 | 1.00 | 2.00 | 0.045 | 0.030 | 12.00 15.00 | 22.00 24.00 | |
310 | 0.25 | 1.50 | 2.00 | 0.045 | 0.030 | 19.00 22.00 | 24.00 26.00 | |
Ferritic St. Steel | ||||||||
405 | 0.08as | 1.00 | 1.00 | 0.045 | 0.030 | - | 11.50 14.50 | |
Martensetic St. Steel | ||||||||
410 | 0.12 | 1.00 | 1.00 | 0.040 | 0.030 | - | 12.5 | |
416A | 0.12 | 1.00 | 1.25 | 0.060 | 0.15 | - | 12.5 | |
420 | 0.23 | 1.00 | 1.00 | 0.040 | 0.030 | - | 12.5 | |
431 | 0.20 | 1.00 | 1.00 | 0.040 | 0.030 | 2.00 | 16.00 |
Product Name | ASTM ASME SA 240 300 Series Stainless Steel Sheets For Structure Building |
Width | 600mm~2500mm |
Thickness | 0.1-100mm |
Length | As required |
Surface | BA/2B/NO.1/NO.4/8K/HL |
Stock or not | enough stock |
Quality test | Mill Test Certificate is supplied with shipment, Third Part Inspection is acceptable |
Payment terms | L/C, T/T (30%DEPOSIT) |
Sample | Provided Freely |
Container Size | 20ft GP: 5898mm(Length)x2352mm(Width)x2393mm(High) 40ft GP: 12032mm(Length)x2352mm(Width)x2393mm(High) 40ft HC: 12032mm(Lengh)x2352mm(Width)x2698mm(High) |
Delivery time | Within 7-10 Working Days |
