Compact FA37 Precision Speed Reduction Parallel Shaft Helical Gearbox Wide Torque Range
Compact FA37 Precision Speed Reduction Parallel Shaft Helical Gearbox Wide Torque Range
Compact FA37 Precision Speed Reduction Parallel Shaft Helical Gearbox Wide Torque Range
Compact FA37 Precision Speed Reduction Parallel Shaft Helical Gearbox Wide Torque Range
Specifications
Brand Name :
HUATAO
Model Number :
HT
Certification :
CE, ISO, TUV
Place of Origin :
China
MOQ :
1
Price :
Negotiatable
Payment Terms :
T/T,L/C,Western Union
Supply Ability :
5000PCS/Per Month
Delivery Time :
25 days
Packaging Details :
Plywood Case
Product Name :
FA37 Precision Speed Reduction Parallel Shaft Helical Gearbox
Key Words :
FA37 Parallel Shaft Helical Gearbox
Application :
Industrial Machinery
Color :
Basis on customer request
Customized :
Available
Package :
Plywood Case
HS Code :
8483409000
Production Capacity :
5000PCS/Per Month
Description

FA37 Precision Speed Reduction Parallel Shaft Helical Gearbox

The FA37 Precision Speed Reduction Parallel Shaft Helical Gearbox offers a wide range of output torque (3.5-15000nm) and speed (0.06-374rpm) options, making it suitable for various applications and industries, such as building material shops and energy & mining industries.

Key features and benefits of FA37 Precision Speed Reduction Parallel Shaft Helical Gearbox:

1. Mounting Flexibility
2. High Efficiency and Reliability
3. Wide Torque Range
4. Compact Design
5. Motor Options
6. Hardened Tooth Surfaces
7. Customization Capabilities

Key Attributes Of FA37 Precision Speed Reduction Parallel Shaft Helical Gearbox

Gearing Arrangement
Helical
Output Torque
3.5-15000Nm
Input Speed
≤1800rpm
Output Speed
0.06-374rpm

Other attributes

Applicable Industries
Industrial Machine: Food Stuff, Ceramics, CHEMICAL, Packing, Dyeing, Woodworking, Glass.
Weight (KG)
45
Place of Origin
China
Customized support
OEM, ODM
Brand Name
HUATAO
Type
F series parallel shaft helical gear reducer
Mounting structure
flange-mounted,feet-mounted,flange-mounted with hollow shaft
Size
F27 F37 F47 F57 F67 F77 F87 F97 F107 F127 F157
Power Range
0.12Kw-200Kw
Ratio
3.37-276.77
Mounting position
M1-M6
Output Form
shaft in left, shaft in right, double shafts
terminal box
0°,90°,180°,270°
Color
Blue
Warranty
12months

Packaging and delivery

Selling Units:
Single item
Single package size:
65X35X45 cm
Single gross weight:
45.000 kg

Model of F Series Gearmotor:

Compact FA37 Precision Speed Reduction Parallel Shaft Helical Gearbox Wide Torque Range

Solid shaft output type F37, F47, F57, F67, F77, F87, F97, F107, F127, F157 reducer
Solid shaft with flange output type FA37, FA47, FA57, FA67, FA77, FA87, FA97, FA107, FA127, FA157 reducer
Hollow shaft output type FF37, FF47, FF57, FF67, FF77, FF87, FF97, FF107, FF127, FF157 reducer
Hollow shaft with flange output type FAF37, FAF47, FAF57, FAF67, FAF77, FAF87, FAF97, FAF107, FAF127 reducer, FAF157 reducer.

Material of F Series Right Angle Parallel Shaft Helical Gearmotor Reducer:

1. Box body: HT250 high-strength cast iron, injection-shaped inner cavity, effectively reduces parts wear；

2. Gear: 20CrMo alloy steel, carbon-nitrogen co-infiltration treatment (maintain tooth surface hardness HRC60 after fine grinding)；

3. Flat key: 45 steel, surface hardness HRC50.

Applications of F Series Right Angle Parallel Shaft Helical Gearmotor Reducer:

The F Series Right Angle Parallel Shaft Helical Gearmotor Reducer is widely applied to the light industry,

food, beer & beverage, chemistry, escalator, automatic storage equipment, construction machinery, steel metallurgy, environmental protection, powerplant, coal, mining, paper, board, stage equipment, automobile, ports (airport and dock), and tobacco machinery, etc, winning extremely good praise around the globe.

Compact FA37 Precision Speed Reduction Parallel Shaft Helical Gearbox Wide Torque Range

Packaging:

Compact FA37 Precision Speed Reduction Parallel Shaft Helical Gearbox Wide Torque Range

FAQ:


1. Can you customize it according to our requirements?
We can design nonstandard products according to the customer's drawing and sample.

2. What's your product range?
speed reducer, gearbox, gear motor, pump, crusher

3. What is the reason why we buy from you?
With over 20 years of production experience and credibility. With a professional engineering team, advanced technology production, and skilled workers.Specialized in the production of reducer. Map sample processing business can be undertaken
