Specifications
Brand Name :
Taicheng
Model Number :
0015
Certification :
ISO
Place of Origin :
CHINA
MOQ :
1 pcs
Payment Terms :
W Beam Rolling Guardrail Barrier Accident Car Transportation Facilities Guardrail
Supply Ability :
100 Meters Per 25 Days Or More Less Time
Product name: :
Safety Roller Barrier
Material :
PU/EVA+Galvanized Beam
Usage :
Road Traffic Safety
Size :
1.2 m*1 m* 1.2 m or Custom
Color :
Yellow,Orange
Description

New Rotating Guardrailhighway Rotating Guardrail And High Quality Pu Foam Roller Guardrail

The highway rotating guardrail (EVA material) is an innovative highway safety system made of high-tech material EVA (ethylene vinyl acetate), designed to improve highway traffic safety and reduce the severity of traffic accidents. The following is a brief introduction to the highway rotating guardrail (EVA material):

New Rotating Guardrail highway Rotating Guardrail And Pu Foam Roller GuardrailNew Rotating Guardrail highway Rotating Guardrail And Pu Foam Roller GuardrailNew Rotating Guardrail highway Rotating Guardrail And Pu Foam Roller GuardrailNew Rotating Guardrail highway Rotating Guardrail And Pu Foam Roller GuardrailNew Rotating Guardrail highway Rotating Guardrail And Pu Foam Roller Guardrail

Material properties:

EVA material: EVA is a polymer material with good elasticity and impact resistance. This material is not only lightweight and durable, but also has excellent energy-absorbing capabilities, which can effectively slow down collision energy and reduce damage caused by accidents.
UV resistance and weather resistance: The highway rotating guardrail is made of EVA material, which has excellent weather resistance and UV resistance, and can maintain stable performance under various climate conditions and extend its service life.

2. Product Introduction

name highway guardrail safety roller barrier use road safety
size 4130*310*81*2.75 standard American standard
material Q345B or Q235B feature anti-corrision
certificate ISO SGS BV CE treatment of surface hot dip galvanized



3. Product Parameters

No. Name Specifications(mm) Material
1 Roller 345*490/350*510(Customized) Polyurethane
2 Post 140*2000*4.5(Customized) Q235
3 PVC Tube 160*500*6.5(Customized) PVC
4 Beam 100*80*4.0 Q235
5 Rolling Circle 182×145×6.0 Polymer Ethylene
6 End Socket 1300×230×4.0 Q235
7 Post Cap 145×145 Rubber
8 Bolt M18*120 Q235
M18*180 Q235
M18*80 Q235
9 Nut M20 Q235

Item Specifications
Apparent Density (KG/m³) ≥125
Tensile Strength(MPa) ≥1.15
Elongation(%) ≥320
Compression Permanent Distortion (%) ≥38
Resilience(%) ≥72


Advantages and features:

Efficient energy absorption: The highway rotating guardrail is made of EVA material, which has excellent energy absorption performance and can effectively slow down collision energy and reduce accident damage.

Lightweight and durable: EVA material is light and durable, not easy to break or deform, and can withstand long-term traffic loads and environmental impacts.

Easy installation: The highway rotating guardrail adopts a modular design, which is easy and fast to install. It can be quickly put into use and improve construction efficiency.

Highway traffic safety: Highway rotating guardrails can be widely used on highways, national highways, provincial highways and other sections to effectively improve traffic safety and reduce the incidence of traffic accidents.

Urban roads: Suitable for urban main roads, secondary main roads and other roads, providing effective protection and safety guarantee for urban traffic.
