Drawn Cup Needle Roller Bearings With Open Ends 25x32x38mm Hk2538 Bkm2538uuh
Drawn Cup Needle Roller Bearings With Open Ends 25x32x38mm Hk2538 Bkm2538uuh
Drawn Cup Needle Roller Bearings With Open Ends 25x32x38mm Hk2538 Bkm2538uuh
Drawn Cup Needle Roller Bearings With Open Ends 25x32x38mm Hk2538 Bkm2538uuh
Specifications
Brand Name :
QRL
Model Number :
Bkm2538uuh
Certification :
ISO9001
Place of Origin :
CHINA
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
10000pcs
Delivery Time :
7-15days
Packaging Details :
Carton/woven bag
Type: :
Needle Roller Bearing
Oe no. :
Bkm2538uuh
Universal number :
HK253238
Certification: :
ISO9001/2008
Size :
25x32x38mm
Quality :
Standrad
Product name :
Needle Bearing
Weight :
0.2kg/pcs
Description

Hk2538 Bkm2538uuh Drawn Cup Needle Roller Bearing 25x32x38mm​

Needle roller bearing Specification

1 Drawn Cup Needle Bearing HK, BK
2 Needle Bearing with Inner Ring NA, NKI
3 Needle Bearing without Inner Ring NK, RNA
4 Full Complement Needle Bearing NAV
5 Radial Needle Roller and Cage Assemblies K, KK
6 Thrust Needle Roller and Cage Assemblies AXK, AS

Needle Roller Bearing Description

The outer ring of drawn cup needle roller bearing is punched with the steel sheet. It has the small sectional height and the large load carrying capacity and is suitable for economic mass production.

The interference fit between outer ring and bearing housing is applied to this kind of needle roller bearing without axial fixing device. Even for the condition of high load, it fully maintains bearing function either. In addition, with the large grease-storage capacity, it is unnecessary to add grease for a long-term operation.

Since one end of the close-end bearing is sealed, it is suitable for the end of shaft with bearing the small axial sliding force.

Model HK, TA, TLA, open-end drawn cup. needle roller bearings with retainer,

Model BK close-end drawn cup needle roller bearing with retainer,

Model SCE, BA, J, JH, drawn cup needle roller bearings(Inch series).

Needle Roller Bearing​ Number

Shaft Diameter (mm) Bearing Designation Boundary Dimensions(mm) Basic Load Rating (N) Limiting Speed (rpm)
Current Designation Original Designation Fw D C Cr Dynamic Cor Static Grease Oil
25 HK2512 27941/25 25 32 12 10200 15400 5800 8800
HK2516 7941/25 25 32 16 14900 22000 5800 8800
HK253216-RS 25 32 16 11100 17100 5800 8800
HK2516-2RS 25 32 16 10200 15400 5800 8800
HK2518 25 32 18 14800 24700 5800 8800
HK2518-RS 25 32 18 13700 22400 5800 8800
HK2520 67941/25 25 32 20 17800 27700 5800 8800
HK2520/AS1 25 32 20 17800 27700 5800 8800
HK2520-2RS 25 32 20 13700 22400 5800 8800
HK253222 7942/25 25 32 22 18500 33000 5800 8800
HK2524-2RS 25 32 24 17800 27700 5800 8800
HK253225 7943/25 25 32 25 20100 36600 5800 8800
HK2526 25 32 26 23100 44000 5800 8800
HK253315 25 33 15 13100 18800 5800 8800
HK253420 014311123D 25 34 20 19000 29300 5800 8800
HK253520 57942/25 25 35 20 19400 27900 5800 8800

Needle Roller Bearing Delivery


Before the contract is placed, the Payment, LASER MARK, plastic bag, box, sticker, carton, carton mark, pallet should be discussed into details. After the order is placed, the products must be manufactured as description. Best quality with acceptable price is our service for all customers. as the deadline is coming, after the payment, the packed goods would be sent to the right place.
