Specifications
Brand Name :
BMS
Model Number :
2 IN 1
Certification :
CE
Place of Origin :
Xiamen, China
MOQ :
1 Set
Price :
Negotiate
Payment Terms :
L/C, T/T
Supply Ability :
30set/month
Delivery Time :
45days
Packaging Details :
The main machine is directly loaded into the container, and the electrical components are wrapped with plastic film.
Forming Station :
19 steps
Shafts Diameter :
φ56mm
Forming Speed :
12-15m/min
Weight :
7T
Material Thicknes0.5-0.8mm or 0.8-1.2mms :
1-2mm
Main Motor :
7.5KW
Description

Dual Door Rail Roll Forming Machine (2-in-1)

Main machine parameter

No Main Item Description
1 Suitable Material Galvanized Steel,Cold Roll Steel
2 Material thickness 1-2mm
3 Material Yield strength

G245-G345
4 Forming station 19 steps
5 Rolled GCr12 steel
6 Shafts Diameter ф56
7 Main power 11kw
8 PLC Brand Siemens/Schneider/Delta
9 Touch Screen Siemens
10 Encoder Omron
11 Exit Rack Unpower, One-units

Dual Door Rail Roll Forming Machine 2 In 1 19 steps

Dual Door Rail Roll Forming Machine 2 In 1 19 steps

1.Main features of dual door rail roll forming machine (2-in-1)


The advantages of dual door rail roll forming machine (2-in-1) are as follows:

1.Accuracy Profile

2.Stable

3.Easy operation, low maintenance cost

4.Beautiful appearance.

5.Customorized for any size you want

2.Detailed Images of dual door rail roll forming machine (2-in-1)

Machine Parts

1) Dual door rail roll forming machine (2-in-1) feeding guide

Brand: BMS Original: China

Dual Door Rail Roll Forming Machine 2 In 1 19 steps

2) Dual door rail roll forming machine (2-in-1) rollers

Rollers manufactured from high quality bearing steel GCr15, CNC lathes, Heat Treatment.

with black treatment or Hard-Chrome Coating for options.

With feeding material guide, body framemade from 200# H type steel by welding

Dual Door Rail Roll Forming Machine 2 In 1 19 steps

Dual Door Rail Roll Forming Machine 2 In 1 19 steps

3) Dual door rail roll forming machine (2-in-1) post cutter

made by high quality mold steel Cr12 with heat treatment HRC58-62

Cutter frame made from high quality 20mm steel plate by welding


Dual Door Rail Roll Forming Machine 2 In 1 19 steps

4)With 3 tons hydraulic decoiler for option

Dual Door Rail Roll Forming Machine 2 In 1 19 steps

5)Other detailes of dual door rail roll forming machine (2-in-1)

Suitable for material with thickness 1.0-2.0 mm

Shafts manufactured from 45#,Main shaft diameter=φ56/75mm,precision machined

Motor driving,Gear chain transmission, 19 rollers to form.

Main motor=7.5KW , Frequency speed control. Forming speed approx.12-15m/min

PLC Control System (Touch screenbrand:German Schneider Electric/Taiwan WEINVIEW,

Inverter brand:Finland VOCAN/Taiwan DELTA/ALPHA,Encoder brand:Japan Koyo/OMRON)

Dual Door Rail Roll Forming Machine 2 In 1 19 steps

6.

Dual door rail roll forming machine (2-in-1) exit rack

Un-powered,3 meters long ,four units

Dual Door Rail Roll Forming Machine 2 In 1 19 steps

7)Product Show

Dual Door Rail Roll Forming Machine 2 In 1 19 steps

Terms Of Trade


1. Minimum order quantity (MOQ): 1 Set.
2. Port of loading: port of Xiamen.
3. Type of payment: by T/T or by L/C.
4. Export:to more than 50 countries and regions, including Taiwan, UK, France, Singapore, Greece, Australia, USA, Mexico, Brazil, Chile, Bolivia, Trinidad, Israel, Saudi Arabia, etc.

Packing style

Packing method: Main body of machine is naked and covered by plastic film(to protect of dust and corrosion),loaded into container
and steadily fixed in container suitable by steel rope and lock, suitable for long-distance transportation.

Dual Door Rail Roll Forming Machine 2 In 1 19 steps

After-Sale Service

1. The warranty is 24 months after the client receives the machine.Within the 24 months, we will courier the replacement parts to the client free of charge.
2. We offer technical support for the entire life of our machines.
3. We can send our technicians to install and train the workers in the clients' factories with extra cost.
