PLC Control Solar Panel Support Rolling Machine Custom Color 22 - 26 Rolls Servo Guiding Device
PLC Control Solar Panel Support Rolling Machine Custom Color 22 - 26 Rolls Servo Guiding Device
PLC Control Solar Panel Support Rolling Machine Custom Color 22 - 26 Rolls Servo Guiding Device
PLC Control Solar Panel Support Rolling Machine Custom Color 22 - 26 Rolls Servo Guiding Device
PLC Control Solar Panel Support Rolling Machine Custom Color 22 - 26 Rolls Servo Guiding Device
PLC Control Solar Panel Support Rolling Machine Custom Color 22 - 26 Rolls Servo Guiding Device
Specifications
Brand Name :
JCX
Model Number :
21*41 and 41*41
Certification :
CE/ISO
Place of Origin :
China
MOQ :
1 set
Price :
USD31000-32500 PER SET
Payment Terms :
L/C, T/T
Supply Ability :
30 SETS roll forming machine
Delivery Time :
20 working days
Packaging Details :
the main machine and PLC and pump are covered with plastic films,the spare parts in carton.
Condition :
New
After-sales service provided :
Engineers available to service machinery overseas
Type :
Solar Panel Support roll forming machine
Tile type :
Roll Forming Machine
Warranty :
12 months
Raw material :
PPGI PPGL GI GL
Voltage :
380V/50HZ 3Phase(as Customer's Request)
Weight :
about 15 tons
Dimension(l*w*h) :
12.5 m*1.3m*1.3m
Description

Full Automatic Solar Panel Support Roll Forming Machine Hardening Treatment Roller Material

1. Machine introduction

Our machine can produce the decoration buckles, light-gauge steel joists, shelf columns, door frame parts and other profiled accessories. It has the advantages such as high production efficiency, stable product sizes, less investments, etc.

Company according to the different industry use produce the different profiled accessory roll forming machines. It is widely used in the areas such as construction decorations, doors manufacturing, shelf fabrication, logistics, etc.

our factory is manufacturing high quality storage rack roll forming machines, and exported to the foreign countries such as IAustralia, Malaysia, Indonesia, Vietnam, Thailand, Russia, Saudi Arabia, Singapore, etc.

1. Profile drawing of solar panel support roll forming machine

PLC Control Solar Panel Support Rolling Machine Custom Color 22 - 26 Rolls Servo Guiding Device

2. Workflow of solar panel support roll forming machine

PLC Control Solar Panel Support Rolling Machine Custom Color 22 - 26 Rolls Servo Guiding Device

3. Main features of solar panel support roll forming machine

The advantages of solar panel support roll forming machine AUTOMATIC size-change type are as follows:
1.Produce different purlin size without changing rollers or spacers.
2.No need changing cutter for different size.
3.Easy operation, low maintenance cost
4.Infinite sizing(any size within machine range),help to save material
5.Optional Punch hole at any position of purlin web side and flange side

4. Supplying components of complete machine

NO. Description Quantity (set) Remark
1 Manual Decoiler 3 Ton 1
2 Guiding device 1 One complete unit as main machine
3 Forming system 1
4 Transmission system 1
5 Flying Saw Cut 1
6 Support table 2
7 Hydraulic station 1
8 Control box 1
9 Spare parts and tools 1 As attaching list
10 Servo motor punching machine 1

5. Detailed Images of solar panel support roll forming machine

Machine Specifications

Weight

About 12 tons

Size

About 15*1.2*1.2m(length x width x height)

Color

Main color: blue or as your requirement

Warning color: yellow

Suitable Raw Material

Material

zinc magnesium aluminum, galvanized sheet ,black belt

Thickness

2.0 mm

Yield Strength

235Mpa

Main Technical Parameters

Quantity of forming rollers stations

18

Diameter of forming rollers shafts

80mm

Roll Forming Speed

15-23m/min

Forming rollers material

No.45 steel, coated with chromed treatment

Cutter material

Cr12MoV steel, with quenched treatment

Controlling system

PLC and Converter

Electric Power requirement

Main motor power: double 15kw hydraulic motor

Electric voltage

According to customer’s requirement

6. Machine picture.
PLC Control Solar Panel Support Rolling Machine Custom Color 22 - 26 Rolls Servo Guiding Device
PLC Control Solar Panel Support Rolling Machine Custom Color 22 - 26 Rolls Servo Guiding Device
7. Our service

A. Foreign debugging

If you need, we will arrange our professional engineers to help you install and debug the machines well. Buyer should pay $60 per day

B. Guarantee period

The warranty will be maintenance, maintain in the guarantee period of 18 months starting from delivery. Because of the quality of equipment during guarantee period, we will provide the parts free of charges, which is in the conditions of correct operation. (Natural disasters or factors which can’t forced by human are excluded).

C. Training

During installation and adjustment of the equipment, our engineers shall provide the training to

buyer’s personnel request to operate and maintain the equipment. Including foundation construction, electrical works, hydraulic oil, safe operation and non-standard safety items, testing material and etc.

D. Lifetime services

Life time services to every customer.

8.Packing and delivery

PLC Control Solar Panel Support Rolling Machine Custom Color 22 - 26 Rolls Servo Guiding Device
.
