STEEL GALVANIZED COIL FLOOR DECKING MACHINE FLOOR DECK FORMING MACHINE
STEEL GALVANIZED COIL FLOOR DECKING MACHINE FLOOR DECK FORMING MACHINE
STEEL GALVANIZED COIL FLOOR DECKING MACHINE FLOOR DECK FORMING MACHINE
STEEL GALVANIZED COIL FLOOR DECKING MACHINE FLOOR DECK FORMING MACHINE
Specifications
Brand Name :
JCX
Model Number :
roll forming machine
Certification :
ISO;CE
Place of Origin :
Hebei
MOQ :
1
Price :
22399
Payment Terms :
L/C, T/T
Supply Ability :
1000
Delivery Time :
45days
Packaging Details :
40GP container
Weight :
10T
Tile type :
Galvanized steel
Roller material :
high grade 45# with heat treatment and chrome coating
Condition :
New
Control system :
PLC with touch screen
Product name :
Cold Steel Roofing Floor Deck
Usage :
floor deck
Cutting system :
Hydraulic cutting
Cutting blade material :
Cr12
Power(w) :
18.5kw
Description
STEEL GALVANIZED COIL FLOOR DECKING MACHINE FLOOR DECK FORMING MACHINE
1. Description of STEEL GALVANIZED COIL FLOOR DECKING MACHINE FLOOR DECK FORMING MACHINE :

Our AUTOMATIC STEEL GALVANIZED STEEL DECK PANEL ROLL FORMING MACHINE ADOPT :

High quality 45#steel by heat treatment

Shaft: full solid 80mm or 90mm as per deck paneldesign and thickness

Main motor by: 18.5kw or 2 sets 15kw for enough power

Embossing shafts to roll different pattens

Control by PLC, INVETER

2. Technical details of STEEL GALVANIZED COIL FLOOR DECKING MACHINE FLOOR DECK FORMING MACHINE :

Machine Specifications
Weight About 10tons
Size About 10mx2.2mx1.3m(length x width x height)
Color Main color: blue
Warning color: yellow
Suitable Raw Material
Material Galvanized Steel Coils
Thickness 0.8-1.5mm
Yield Strength 235Mpa
Main Technical Parameters
Quantity of forming rollers stations 22-25
Diameter of forming rollers shafts8 80/90mm
Roll Forming Speed 12-15m/min
Forming rollers material No.45 steel, coated with chromed treatment
Cutter material CR12 mould steel, with quenched treatment
Controlling system PLC and Converter
Electric Power requirement Main motor power: 2*11kw
Hydraulic unit motor power: 5.5kw
Electric voltage According to customer’s requirement

3. Main components of door shutter roll forming machine

Decoiler 1 Set
Guiding Equipment 1 Set
Roll Forming Unit 1 Set
Post Cutting Unit 1 Set
Hydraulic Station 1 Set
PLC Control System 1 Set
Reveiving Table 1 Set
Hydraulic pre cutting system Optional

4. Production Flows:

Uncoiling the sheet---Infeed guiding--Embossing shafts----Roll forming-----Measure length---Cutting the panel--panels to the supporter (option: automatic stacker)

5. Advantages:

· 5 engineers with more than 20 years experience

· 30 professional technician

· 22 sets advanced CNC production lines on site

· Passionate Team

· Installation engineers can reach your factory within 6 days

· 2 years maintenance and whole life technical support

STEEL GALVANIZED COIL FLOOR DECKING MACHINE FLOOR DECK FORMING MACHINE

STEEL GALVANIZED COIL FLOOR DECKING MACHINE FLOOR DECK FORMING MACHINE

STEEL GALVANIZED COIL FLOOR DECKING MACHINE FLOOR DECK FORMING MACHINE

STEEL GALVANIZED COIL FLOOR DECKING MACHINE FLOOR DECK FORMING MACHINE
STEEL GALVANIZED COIL FLOOR DECKING MACHINE FLOOR DECK FORMING MACHINE
Company Profile
STEEL GALVANIZED COIL FLOOR DECKING MACHINE FLOOR DECK FORMING MACHINE
BOTOU Golden Integrity roll forming machine
BoTou Golden Integrity Roll Forming Machine Factory is located in "the town of casting molds", Our factory has highly qualified and experienced professionals and highly skilled construction workers to serve you.
You are welcome to contact us for more information.
STEEL GALVANIZED COIL FLOOR DECKING MACHINE FLOOR DECK FORMING MACHINE
