6feet Automatic Bird Cage Welded Wire Mesh Making Machine
6feet Automatic Bird Cage Welded Wire Mesh Making Machine
Specifications
Brand Name :
Huayang
Model Number :
R-DHW
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
20 sets/month
Delivery Time :
30 days
Packaging Details :
1.Machine will be covered with plastic film and fastened by steel wire in container. 2. Spare parts will be packed into carton box and fastened stable in container.
Product name :
Automatic Bird Cage Drive Shaft Welding Machine
Trademark :
Huayang
Electrodes :
Single or double row
Mechanical Specifications :
According to Customer Requirement
Pressure way  :
Spring-weighted
Voltage :
220V/380V/415V/440V
Welding Way :
Spot Welding
Warranty :
12 Months After Installation
Mesh Type :
in Roll
Description

Automatic Bird Cage Drive Shaft Welding Machine

1. Product description

Automatic Bird Cage Drive Shaft Welding Machine is used for making wire mesh. At the same time, the machine is also equipped with automatic cutting mesh machine, when the machine finishes the mesh length according to the setting parameters, the mesh will be cut by the cutting mesh machine automatically.

2. Technical parameter

Model Mesh width Minimum mesh size (inch) Wire diameter(mm) Welding speed (rows/min) Roll mesh length (m) Other available mesh size (inch)
R- DHW 6 feet 1/2x1/2 0.45-0.85 90-120 130 1/2x1, 1x1/2, 1x1, 2x2
R- DHW 6 feet 1/2x1/2 0.6-1.3 90-120 110 1/2x1, 1x1/2, 1x1, 2x2
R- DHW 6 feet 1/2x1/2 0.8-1.6 80-90 100 1/2x1, 1x1/2, 1x1, 2x2
R- DHW 6 feet 1x1 0.45-0.85 90-120 130 1x2, 2x1, 2x2, 2x4
R- DHW 6 feet 1x1 0.6-1.3 90-110 110 1x2, 2x1, 2x2, 2x4
R- DHW 6 feet 1x1 0.8-1.6

90-110

 100 1x2, 2x1, 2x2, 2x4
R- DHW 6 feet 1x1 1.4-2.6 80-90 80 1x2, 2x1, 2x2, 2x4


3. Application area

Automatic Bird Cage Drive Shaft Welding Machine is the most widely used material for fences and cages. It also plays a vital, load-bearing role in oven and barbecue grills, refrigerator shelves and racks, shopping carts and dishwasher baskets. Further, it is used in reinforced mesh to lend stability to concrete.

4. Advantages

a. Spooling machine, repair table, we use good material to guarantee it is sturdy and stable, easy to operate.


b. The welding head is made of chromium-zirconium copper, with good electrical conductivity, hard material and abrasion resistance.

c. The electric current, line and weft opening are adjustable.
