Drive Shaft 6feet Roll 380v Automatic Wire Mesh Welding Machine
Drive Shaft 6feet Roll 380v Automatic Wire Mesh Welding Machine
Specifications
Brand Name :
Huayang
Model Number :
R-DHW
Certification :
CE
Place of Origin :
Hebei province, Huanghua city
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
20 sets/month
Delivery Time :
30 days
Packaging Details :
1.Machine will be covered with plastic film and fastened by steel wire in container. 2. Spare parts will be packed into carton box and fastened stable in container.
Product name :
Automatic Six Feet 380V Roll Mesh Drive Shaft Welding Machine
Mesh roll length :
about 100m
Electrodes :
Single or double row
Power :
5kw,10kw
Mesh shape :
Square
Voltage :
220V/380V/415V/440V
Welding Way :
Spot Welding
Application :
Building&Construction
After-sales Service :
Free spare parts, Online support, Video technical support
Description

Automatic Six Feet 380V Roll Mesh Drive Shaft Welding Machine

1. Product description

Automatic Six Feet 380V Roll Mesh Drive Shaft Welding Machine is used for making wire mesh. The feature of the machine is saving materials and high capacity. The button switches to start and stop machine easily. The galvanized iron wire green roll mesh welding machine can be quick and easy roll extraction from the machine.

2. Technical parameter

Model Mesh width Minimum mesh size (inch) Wire diameter(mm) Welding speed (rows/min) Roll mesh length (m) Other available mesh size (inch)
R- DHW 6 feet 1/2x1/2 0.45-0.85 90-120 130 1/2x1, 1x1/2, 1x1, 2x2
R- DHW 6 feet 1/2x1/2 0.6-1.3 90-120 110 1/2x1, 1x1/2, 1x1, 2x2
R- DHW 6 feet 1/2x1/2 0.8-1.6 80-90 100 1/2x1, 1x1/2, 1x1, 2x2
R- DHW 6 feet 1x1 0.45-0.85 90-120 130 1x2, 2x1, 2x2, 2x4
R- DHW 6 feet 1x1 0.6-1.3 90-110 110 1x2, 2x1, 2x2, 2x4
R- DHW 6 feet 1x1 0.8-1.6

90-110

 100 1x2, 2x1, 2x2, 2x4
R- DHW 6 feet 1x1 1.4-2.6 80-90 80 1x2, 2x1, 2x2, 2x4


3. Application area

Automatic Six Feet 380V Roll Mesh Drive Shaft Welding Machine is widely used in prevention for road, railway, airport, residence district, seaport, garden, feeding and husbandry.


4. Advantages

a. To increase safety of machine, we protect every transmission part(chain,rotate)with protective cover,and add switch in the electric cabinet.


b. To strengthen easy operation of machine,we use proximity switch between upper and lower welding heads,when cross wire doesn't reach,the machine will stop automatically.

c. Namely one worker can both operate wire mesh welding machine and repairing wire mesh,thus greatly improve the work efficiency and save labor.
