1. Water-proof, moisture-proof, insect-resistant. Avoid bugs crawl into the machine, and all kinds of malfunctions causes such as wet.
2. Exquisite ,with drawable printer,easy to take out paper and replace paper, simple and convenient operation.
3. Support PLU updating on line and editing, ensure the item all the latest information.
4. Storage capacity up to 10000 pieces commodities and support 224 hotkeys. Set menu shortcuts, through the PC software can adjust the hotkey sequence and print it out.
5. Each item could choose any tag from independently. Multiple barcode optional,such as 8 bit,13 bit, and 18 bit.
6. Can set up different types and information, etc according to different items. It advantageous to the commodity classification management.
7. Support Labels and barcode rotated 90 degrees, or 270 degrees printing.
8. Support to be connected by Ethernet interface, Software can be upgraded online, to meet customer's special demand.
9. More rich label content. can print production date, date of packaging, fresh date, expiration date, Select it according to clients requirements.
10. Searching products quickly by product No.
11. Support discount schedule, discount period setting.
12. Support for multiple foreign languages, labels, such as background, the name of the item etc.
13. Support double screen dot matrix display, easy to promote products.
14. Support receipt paper and label paper printing.
15. Dual-motor design, printing more efficient and stable.
Capacity | Max capacity | 6kg/15kg 15kg/30kg |
Min capacity | 40g 100g | |
Interval | 2/5g 5/10g | |
Accuracy class | III | |
Basic | COG | LCD 256X32 |
SDRAM | 8MB | |
FLASH | 16MB | |
Ethernet | 1 x RJ45 | |
Serial | 1 x RS232 | |
Power source | 1 x AC Jack | |
Input | AC100V-240V 50/60Hz 1.5A | |
Buttons | Hotkeys:112*2;Preset keys:28 | |
Notification | Buzzer | |
Dimension | 433(L) × 372(W) × 506(H)mm | |
Communication | Ethernet | TCP/IP 100M |
Wi-Fi(Optional) | IEEE 802.11 b/g/n,2.4GHz | |
Printer | Printing | Thermal print |
Print width | MAX 56mm | |
Print speed | 90 m/s | |
Printer resolution | 203 DPI | |
Paper out | Auto peel off | |
Barcode format | 2/5 interleaved, 128 ,EAN13,GS128 | |
Reliability requirements | Certification | OIML,CE, Type evaluation, NTEP:RLS1000(RLS1200) |
Implementation standards | GB/T 7722-2020,OIML R 76-1(2006) and EN 45501:2015 | |
Operation environment | Operating temperature | 0℃ ~+40℃ |
Operating humidity | 20%~85% | |
Storage temperature | -20℃~+60℃ | |
Operating temperature | 5%~95% | |
Packaging material | Standard | ■Kraft paper■Styrofoam |
■Power cable■Scale pan■Warranty card■Certificate■User manual |
