Long Lasting RP203 Panel Mount Thermal Printer With TTL/RS232 Interface
Long Lasting RP203 Panel Mount Thermal Printer With TTL/RS232 Interface
Specifications
Brand Name :
RONGTA
Model Number :
RP203
Certification :
CE, FCC, 3C
Place of Origin :
CHINA
MOQ :
For OEM 300 units
Price :
$13-$15/unit
Payment Terms :
T/T, L/C
Supply Ability :
100000 units per year
Delivery Time :
OEM/ODM 25-35 days
Packaging Details :
8 pcs per carton, 17.5kgs/CTN
Print method :
Direct thermal print and auto paper feed
Printing width :
48 mm
Max printer speed :
85 mm/s（max.）
Command system :
ESC printer command/WH printing command
Printing head lifespan :
50km
Papaer thickness :
65±5um
Paper Thickness :
0.06-0.10 mm
Dimension (WⅹHⅹD mm) :
76.8mm*77.4mm*43.5mm
Printer interface :
TTL/RS232
Description
Long Lasting RP203 Panel Mount Thermal Printer With TTL/RS232 Interface

1.Fashionable ,delicate and elegant.
2.Low noise direct thermal printing method.
3.Paper out detection,automatic memory printing function.
4. RS232/TTLl interface.
5.Easy paper loading.

Long Lasting RP203 Panel Mount Thermal Printer With TTL/RS232 Interface

Paper Working Loading way easy
Cutting way divulsion(dentiform)
Printer Performance Print method direct thermal print and auto paper feed
Printing density 384 dots/line
8 dots/mm
Printing width 48 mm
Max printer speed 85 mm/s(max.)
Dot distance 0.125 mm
Drawing/Bar code Word size(WxH mm) 0.75×1
ASCII Character(WxH dots) 16 lattice:8×16; 24 lattice:12×24
ASCII Size(WxH mm) 16 lattice:1×2; 24 lattice:1.5×3
Drawing/bar code suitable
Testing Method Lacking paper testing photoelectricity sensor
Control System Printer interface TTL/RS232
Buffer 32k
Command system ESC printer command/WH printing command
Power Woking voltage DC3.5V--9V (from7.2-7.5V,with highest speeed and excellent effect)
Current 2.5A-3A
Printer Mechanism Printing head lifespan 50km
Paper Paper item thermal paper
Paper width 58mm
Papaer thickness 65±5um
Diameter of paper roll 30mm
Environment Operating temperature/humidity 0~50℃/10%~80% RH
Storage temperature /humidity -20~60℃, 10%~90% RH
Physics Specification Dimension (WxHxD mm) 76.8mm*77.4mm*43.5mm

FAQ:

1, Q: Are you a factory or trading company?

Rongtatech: we are a manufacturer, owning the professional design group, skill-full staffs and quality inspection team, located in Gaoqi Hi-tech Industry Area, Xiamen city, China.

2, Q: We would like to have our own brand, is that ok?

Rongtatech: Yes, we can accept OEM/ODM with your brand or your design. But we will require a MOQ for different models.

3, Q: Besides the English language, do your printers support other languages? And what operation system they backup?

Rongtatech: Yes, our printer not only supports English language, but also Russian, Spanish, Portuguese etc 48 different languages available, and it backups IOS, Android, Windows, Linux, Oppos operation systems.

4, Q: How can I get a sample?

Rongtatech: It is our honor to supply sample for your evaluation. Please contact the salesperson by informing the model# and your requirements, then we will send the sample by such DHL, Fedex, after your sample order get confirmed.

5, Q: What sale after service do you offer?

Rongtatech: Each printer will have 12 months warranty. Free components will be offered for repair in warranty period, if the issue caused by non-artificial damages.

We will offer technical supports or helps in your daily use for lifetime and offer latest software for your updating.
