3MM PVC ASA Plastic 75kw Corrugated Roof Sheet Making Machine
3MM PVC ASA Plastic 75kw Corrugated Roof Sheet Making Machine
3MM PVC ASA Plastic 75kw Corrugated Roof Sheet Making Machine
3MM PVC ASA Plastic 75kw Corrugated Roof Sheet Making Machine
3MM PVC ASA Plastic 75kw Corrugated Roof Sheet Making Machine
3MM PVC ASA Plastic 75kw Corrugated Roof Sheet Making Machine
Specifications
Brand Name :
ACEMIEN
Model Number :
pvc roof tile machine
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 SETS
Price :
USD8800-12800 PER SET
Payment Terms :
L/C, T/T
Supply Ability :
50 sets per year
Delivery Time :
85 working days
Packaging Details :
film and wooden carton
Application :
Plastic Roof Tile Machine,producing PVC sheet
Voltage :
380V 50HZ 3Phase(Customized)
Automatic grade :
High
Condition :
New
Plastic processed :
PVC
Screw design :
Double-screw
After-sales service provided :
Engineers available to service machinery overseas
Power(w) :
75KW
Warranty :
12 months
Raw material :
PVC/ASA/PMMA,ASA + PVC
Description

High efficiency PVC+ASA plastic Corrugated roof sheet making machine

Machine name:

High efficiency PVC+ASA plastic Corrugated roof sheet making machine

Finshed product:

Plastic roofing making machine,Plastic corrugated roofing,1mm-3mm thickness,customized length

Product application:

Plastic PVC roof making machine used for Roofing, can be used for factories, warehouses, sheds, farmers market, hoardings, walls, temporary shops, sheds and other very suitable insulation.

Roof tile making machine is manufactured based on 2 or 3 or 4 layer co-extrusion technology by one-time processing,which well combine the different functions of raw materials(PVC+ASA) so that the tile can be anti-corrosive, fire retardant, eco-friendly, more durable, tenacious, easy to install and move, light weight as well as cost effective in installation (as less steel and less overlap), as per the efficiency and benefits it provides

3MM PVC ASA Plastic 75kw Corrugated Roof Sheet Making Machine

Product info:

Material

Surface layer:ASA (Granule)

Bottom layer:PVC powder, CaCO3, CPE, PE-WAX, Stearic acid, Compound stabilizer, ACR, paraffin
Cost

Surface layer:USD 3400/T, Need 100g/㎡

Bottom layer:USD 300-USD 500/T
Weight 3-5kg/square meter
Thickness 1.5mm,2mm,2.5mm,3mm(adjustable)
Profit

Product cost USD 1.7-USD 3/㎡

Normally in market sell at USD 2.7-5 / ㎡ even more

Profit:at least USD1-2/㎡

3MM PVC ASA Plastic 75kw Corrugated Roof Sheet Making Machine

Main Machine List
No. Name Qty. Remark
1 Screw loader for SJZ 80/156 extruder 1
2 SJZ 80/156 conical twin-screw extruder 1 For the PVC layer
3 Vacuum loader for SJ65 extruder 1
4 drying hopper for SJ65 extruder 1
5 SJ65/30 single screw extruder 1
6 SJ50/30 single screw extruder(ASA)
7 1300mm Mould unit 1 Product width:1050mm
8 Distributor 1
9 Cutter 1
10 Stacker 1

3MM PVC ASA Plastic 75kw Corrugated Roof Sheet Making Machine

3MM PVC ASA Plastic 75kw Corrugated Roof Sheet Making Machine

Function:make roof tile.


Type 1: make corrugated tile forming machine with a length counter.
type 2: make glazed tile forming machine witha wave counter.

3MM PVC ASA Plastic 75kw Corrugated Roof Sheet Making Machine

3MM PVC ASA Plastic 75kw Corrugated Roof Sheet Making Machine
