PLC Controlled Arch Curving Roof Roll Forming Machine High Productivity
PLC Controlled Arch Curving Roof Roll Forming Machine High Productivity
PLC Controlled Arch Curving Roof Roll Forming Machine High Productivity
PLC Controlled Arch Curving Roof Roll Forming Machine High Productivity
Specifications
Brand Name :
CANGZHOU
Model Number :
Hydraulic Crimping
Certification :
ISO CE
Place of Origin :
CHINA MAINLAND
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
L/C, T/T, D/A, D/P
Supply Ability :
40 Sets Per Month
Delivery Time :
30 Working Days
Packaging Details :
20' FLC
Product Name :
Arch Curving Roof Roll Forming Machine/Curved Roof Roll Forming Machine
Raw Material :
PPGL,GL，PPGI,GI，
Dimension(L*W*H) :
8900mm*2230mm*2300mm
Rolling thinckness :
0.6-1.5mm
Shaft material :
45# Steel Outer
Main frame :
350H Steel
Control System :
PLC
Voltage :
380v50hz3ph
Description

Arch Curving Roof Roll Forming Machine/Curved Roof Roll Forming Machine

1 More efficient and accurate execution of production orders;

2. High equipment reliability;
3. Little waste of materials and energy;
4. High productivity;
5. High quality materials, get a longer service life;
6. All parts of the machine are processed with precision, and the surface of the roll is chromeplated to ensure that customers can get qualified products at the same time, it can avoid the scratch of the color steel surface paint, and increase the service life of the roll;
7. Customized coil processing solutions to solve all aspects of technical problems.

All the control system of our machines we make by ourselves. we have a professional engineer to design and make the control system. This can make sure the after-sale service, when customer have problem with control, we can solve it timely.curving roof sheet cold roll forming machine roof curving cold roll forming machinery

Specification

No.
Item
parameter
1
machine size
8900mm*2230mm*2300mm
2
Feeding width
914-1250mm
3
Equipment weight
0.5T
4
Material of shaft
45#steel adjustable treatment
5
Out diameter of shaft
φ70mm
6
Material of roller
Cr12, hard chromize coated HRC58-60°C
7
Number of forming rollers
3-4 rows
8
Main frame
300 H steel
9
Thickness of medium plate
16mm
10
Thickness of formed steel
0.3-0.8mm
11
Main motor power
4 KW
13
Forming speed
 8-10m/min
15
Removable or not
Removable type with 4 wheels
16
Product name
IBR metal sheet curve forming machine

Application

This Curved roofing arch sheet building machine hydraulic crimping machine will be very smooth and beautiful without any scratch on surface.Rollforming process:uncoiler, rollforming, forming step effect, cut to length.Fully Automatic Control System with PLC.Easy operation: Key in the length and quantity on the control panel.

Payment terms

40% in advance.

60% before the shipment is processed.

Delivery

FOB Tianjin Xingang Port or CNF Designated port

The Delivery Time: 30 days after the down payment is received
