3phases Rain Water Downspout Roll Forming Machine Suitable Materials Thickness 0.4-0.8mm
3phases Rain Water Downspout Roll Forming Machine Suitable Materials Thickness 0.4-0.8mm
3phases Rain Water Downspout Roll Forming Machine Suitable Materials Thickness 0.4-0.8mm
3phases Rain Water Downspout Roll Forming Machine Suitable Materials Thickness 0.4-0.8mm
3phases Rain Water Downspout Roll Forming Machine Suitable Materials Thickness 0.4-0.8mm
3phases Rain Water Downspout Roll Forming Machine Suitable Materials Thickness 0.4-0.8mm
3phases Rain Water Downspout Roll Forming Machine Suitable Materials Thickness 0.4-0.8mm
3phases Rain Water Downspout Roll Forming Machine Suitable Materials Thickness 0.4-0.8mm
3phases Rain Water Downspout Roll Forming Machine Suitable Materials Thickness 0.4-0.8mm
3phases Rain Water Downspout Roll Forming Machine Suitable Materials Thickness 0.4-0.8mm
Specifications
Brand Name :
CANGZHOU WILLING
Model Number :
Downspout Plus Elbow
Certification :
ISO CE
Place of Origin :
CHINA MAINLAND
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
L/C, T/T, D/A, D/P
Supply Ability :
20 Sets Per Month
Delivery Time :
30 Working Days
Packaging Details :
20' FLC
Product Name :
Aluminum Elbows Rectangular / Round Elbows Downspout Roll Forming Machine
Raw Material :
PPGI，AL，GI
Voltage :
380V 50Hz 3phases
Control system :
PLC
After-sales service provided :
whole service life technical support
Warranty :
1 year
Description

Rain Water Downspout Roll Forming Machine Elbow Bending Suitable Materials Thickness 0.4 - 0.8mm

Downspout elbows connect to downspouts. In order to fit inside another elbow or downspout, one end of the gutter elbow is crimped. To direct drainage in a particular direction, downspouts are equipped with elbows at ground level.
Profile
3phases Rain Water Downspout Roll Forming Machine Suitable Materials Thickness 0.4-0.8mm
Specification

No. Item Description
1 Coil Galvalume, Galvanized, PPGI
2 Raw Material Thickness 0.3 mm - 0.8 mm
3 Working Speed 8-15 m/min
4 Roller Station 20 Stations
5

Dimension (L*W*H)

 9200 mm*800 mm*1200 mm
6 Machine Weight 9000 KG
7

Electrical Control System

PLC (can be customized)
8

Drive Motor Power

 5.5 KW
9

Hydraulic Station Power

 4 KW
10

Power Supply

380V, 60HZ, 3 PHASES(can be customized)
11

Cutting Accuracy

± 2 mm
12

Driving Mode

Single Chain 1 inch
13

Material of Shaft

60 mm 45#steel forged
14 Material of Roller

45# Steel Finish Machining, Plated Hard

Application

Guarantee

1. Guaranteed against malfunctions due to manufacturing defects for1 years after date of purchase except Electrical parts.

2. Repairs will not be performed even during the guarantee period in the follow circumstances

- Damage occurs due to a natural disaster

- Malfunction occurs due to user error

- Malfunction occurs due to modifications

- Malfunction occurs due to further movement or shipment after installation

Payment terms

40% in advance as down payment

60% is paid before the shipment is processed

Delivery

FOB: Tianjin Xingang Port

The Delivery Time: 30 days after the down payment is received.
