Specifications
Brand Name :
Shenglin
Model Number :
KFXG series
Certification :
CE
Place of Origin :
China
MOQ :
1 pcs
Price :
1500~3500USD
Payment Terms :
T/T, Western Union
Supply Ability :
1000 PCS/month
Delivery Time :
18~20 days
Packaging Details :
Plywood case
COP :
2.9~3.0
Compressor :
Copeland brand
Air side heat exchanger type :
Finned heat exchanger
Water side heat exchanger type :
Casing/high efficiency tank
Supply power :
380V 3N~50Hz
Refrigerant :
R134A, R22, R407C and R410A
Working ambient temperature :
-7~45℃
Air out type :
Top discharge
Heating capacity range :
13~52kW
Max water outlet temp. :
85° C
Application :
Satisfy most water demand for high temperature water in industrial production.
Remark :
Can do OEM
Description

Industrial Use High Temperature Hot Water Heat Pump

Description:

This high temperature hot water heat pump adopts EVI scroll compressor and capable producing hot water with maxiamum temperature up to 85℃, which is ideal for both commercial and industrial applications to kill legionellae and some other bacteria. It uses R134A refrigerant, which is not only eco-friendly but also reliable and stable especially for the system producing high temperature hot water. Suitable: satisfy most water demand for high temperature water in industrial production.

Features:

Intelligent control: Micro processor based digital controller with LCD display.
Durable- more than 15 years life span.
Adjustable water temperature setting: 25~85℃
EVI scroll compressor specially designed for high water temperature heat pump.
ECO-friendly refrigerant R134A
High effciency tube-in-shell water heat exchanger.
Easy installation and operation.

Optional:

Galvanized metal cabinet or stainless steel cabinet.
Refrigerant: R22, R407C and R410A is available


Technical paramater:

High temperature Industrial hot water heat pump
MODEL KFXG-013UAII KFXG-026UAII KFXG-052UAII
Ambient temp. range ℃ -7~45℃
Rated heating capacity KW 13 26 52
COP W/W 2.9 3 3
Heating input power KW 4.48 8.67 17.3
Max. running current A 12.5 26 48
Power supply / 380V 3N~50Hz
IP code / IPX4
Safety function / High and low pressure protection,Overload protection,Temperature protection
Power phase sequence protection, etc.
Refrigerant type/weight -/kg R134a/4.25 R134a/4.5×2 R134a/7.5×2
Compressor QTY PCS 1 2 2
Compressor type / Scroll
Max.temp.outlet water ℃ 80
Water side heat exchanger type / High efficiency tank/stainless steel/Casing
Air side heat exchanger type / Finned heat exchanger
Waterpipe Nozzle size inch G1'' Internal thread G1 1/2'' Internal thread DN80
Rated water flow m³/h 2.2 4.5 8.9
Air out type / Top discharge
Fan motor QTY PCS 1 2 2
Noise dB/(A) 56 65 69
Machine dimension (W×D×H) mm 750×690×1070 1500×690×1070 2100×1100×2000
Packing dimension (W×D×H) mm 800×740×1200 1550×740×1200 2140×1200×2040
Net weight kg 130 320 700
Gross weight kg 150 370 800
Remarks:
1. Test conditions: (DB/WB) 20°C/15°C, inlet water temperature 60°C, outlet water temperature 65°C.
2. Due to product improvement, above datas are subject to change without prior notice, please take the rating plate as standard.

Packing:

Hot Water 52KW Rooftop Heat Pump High Temperature Rooftop Hvac Units Hot Water 52KW Rooftop Heat Pump High Temperature Rooftop Hvac Units

Schematic:

Hot Water 52KW Rooftop Heat Pump High Temperature Rooftop Hvac Units
