Specifications
Brand Name :
FANBAO
Model Number :
F37, F47, F57, F67, F77, F87, F97, F107, F127, F157 FA37, FA47, FA57, FA67, FA77, FA87, FA97, FA107, FA127, FA157 FF37, FF47, FF57, FF67, FF77, FF87, FF97, FF107, FF127, FF157 FAF37, FAF47, FAF57, FAF67, FAF77, FAF87, FAF97, FAF107, FAF127, FAF157
Certification :
CE
Place of Origin :
china
MOQ :
1
Price :
negotiation
Payment Terms :
T/T
Supply Ability :
100sets per month
Delivery Time :
8-15work days
Packaging Details :
standard export wooden case
Output Torque :
10.6-952000NM
Input Speed :
750-1500rpm
Output Speed :
14-280rpm
Warranty :
1 year
Color :
customer Requirement
Ratio :
3.77~276.77
Efficiency :
94%~98%(depends on the transmission stage)
Mounting Position :
Flange, hollow shaft, solid shaft
Description

Parallel Shaft Helical Geared Motor F Series Gear Reducer For Agitator

Description :

F series reducer is a kind of gear is used to reduce the motor speed and improve the output torque of the principle of speed reducer. It uses the gear and gear meshing, with advanced design and novel structure of retarding mechanism.
It has been widely used in harbor and shipping,electric power,coal mining,cement and construction,paper and light industry.

Feature

• High efficiency and save power.
• High modular design, flexible mounting mode.
• Integrated casting housing,compact dimension, stable transmitting and low noise level.
• Perfect oil leakage preventing makes the good sealings and can be used in wide range of industry.
• Advanced gear grinding and modified profile, high loading support and more safe operation.

Apart of type specification :

SIZE 37 47 57 67 77 87 97 107 127 157
DF DFA DFF DKAZ DFAF DFAZ
INPUT POWER RATING(KW) 0.18-0.30 0.18-3.0 0.18-5.5 0.18-5.5 0.37-11 0.75-22 1.1-30 2.2-45 7.5-90 11-260
RATIO 3.81-128.51 5.06-189.39 5.18-199.70 4.21-228.99 4.20-271.92 4.12-270.64 4.68-270.64 6.20-255.25 4.63-172.33 12.07-270.18
MAX TORQUE(N.m) 200 400 600 820 1500 3000 4300 7840 12000 18000
WEIGHT(KG) 13 18 34 55 90 150 260 402 700 950

Mounting position and Position of the motor terminal box :

Parallel Shaft F Series Gearbox Helical Geared Motor Reducer For Agitator
Parallel Shaft F Series Gearbox Helical Geared Motor Reducer For AgitatorParallel Shaft F Series Gearbox Helical Geared Motor Reducer For AgitatorParallel Shaft F Series Gearbox Helical Geared Motor Reducer For Agitator

Parallel Shaft F Series Gearbox Helical Geared Motor Reducer For Agitator

Application :
Industrial Machine: Food Stuff, Ceramics, CHEMICAL, Packing, Dyeing,
Wood working, Glass.
F series process :
Parallel Shaft F Series Gearbox Helical Geared Motor Reducer For Agitator
Packing and shipping way :
Parallel Shaft F Series Gearbox Helical Geared Motor Reducer For Agitator
Why choose us ?
1) With excellent quality and Reasonable price
(2) Promise to delivery on time
(3) Safe, reliable, economical and durable
(4) Stable transmission, quiet operation
(5) High heat-radiating efficiency, high carrying ability
(6) Every product must be tested before sending
