750rpm-1500rpm Hollow Shaft Bevel Helical Speed Reducer Gearbox Reducer With Motor
750rpm-1500rpm Hollow Shaft Bevel Helical Speed Reducer Gearbox Reducer With Motor
750rpm-1500rpm Hollow Shaft Bevel Helical Speed Reducer Gearbox Reducer With Motor
750rpm-1500rpm Hollow Shaft Bevel Helical Speed Reducer Gearbox Reducer With Motor
750rpm-1500rpm Hollow Shaft Bevel Helical Speed Reducer Gearbox Reducer With Motor
750rpm-1500rpm Hollow Shaft Bevel Helical Speed Reducer Gearbox Reducer With Motor
750rpm-1500rpm Hollow Shaft Bevel Helical Speed Reducer Gearbox Reducer With Motor
750rpm-1500rpm Hollow Shaft Bevel Helical Speed Reducer Gearbox Reducer With Motor
750rpm-1500rpm Hollow Shaft Bevel Helical Speed Reducer Gearbox Reducer With Motor
750rpm-1500rpm Hollow Shaft Bevel Helical Speed Reducer Gearbox Reducer With Motor
750rpm-1500rpm Hollow Shaft Bevel Helical Speed Reducer Gearbox Reducer With Motor
750rpm-1500rpm Hollow Shaft Bevel Helical Speed Reducer Gearbox Reducer With Motor
Specifications
Brand Name :
FANBAO
Model Number :
F37, F47, F57, F67, F77, F87, F97, F107, F127, F157 FA37, FA47, FA57, FA67, FA77, FA87, FA97, FA107, FA127, FA157 FF37, FF47, FF57, FF67, FF77, FF87, FF97, FF107, FF127, FF157 FAF37, FAF47, FAF57, FAF67, FAF77, FAF87, FAF97, FAF107, FAF127, FAF157
Certification :
CE
Place of Origin :
china
MOQ :
1
Price :
negotiation
Payment Terms :
T/T
Supply Ability :
100sets per month
Delivery Time :
8-15work days
Packaging Details :
standard export wooden case
Output Torque :
10.6-952000NM
Input Speed :
750-1500rpm
Output Speed :
14-280rpm
Warranty :
1 year
Color :
customer Requirement
Ratio :
3.77~276.77
Efficiency :
94%~98%(depends on the transmission stage)
Mounting Position :
Flange, hollow shaft, solid shaft
Certificate :
ISO9001. CE
Applicable Industries :
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Home Use, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company
Description

F / FA / FAF / FAZ series helical gearbox reducer with motor

Description :

F Series Helical Gear Reducer could enhance your industrial set up . the F Series helical gear reducer is a sleek design, these axis-parallel gear units pack a punch with a robust power range spanning from 130 to 18,000 Nm. When space is at a premium, these gear units stand out as a reliable choice.

The F series parallel-shaft helical gear units are tailor-made for constrained installation spaces. Offering a diverse array of mounting positions and variants, they excel across a wide range of applications, even in challenging installation scenarios. Expect top-tier performance without any compromises. Plus, enjoy the longevity and maintenance-free operation characteristic of our gear units, boasting wear-free gearing with exceptional fatigue strength.

Ranging from 130 Nm to 18,000 Nm in torque rating, our parallel-shaft helical gear units excel in conveying and processing applications. Choose from foot-, flange-, or shaft-mounted options to suit your specific needs. Need precision in positioning tasks? Opt for our parallel-shaft helical gear units with reduced backlash for seamless operations.

Model:

F37, F47, F57, F67, F77, F87, F97, F107, F127, F157
FA37, FA47, FA57, FA67, FA77, FA87, FA97, FA107, FA127, FA157
FF37, FF47, FF57, FF67, FF77, FF87, FF97, FF107, FF127, FF157
FAF37, FAF47, FAF57, FAF67, FAF77, FAF87, FAF97, FAF107, FAF127, FAF157
FAZ37, FAZ47, FAZ57, FAZ67, FAZ77, FAZ87, FAZ97, FAZ107, FAZ127, FAZ157

FS37, FS47, FS57, FS67, FS77, FS87, FS97, FS107, FS127, FS157
F37R17, F47R17, F57R37, F67R37, F77R37, F87R57, F97R57, F107R77, F127R77, F107R77, F127R77, F127R87, F157R97
FAS37, FAS47, FAS57, FAS67, FAS77, FAS87, FAS97, FAS107, FAS127, FAS157
FA37R17, FA47R17, FA57R37, FA67R37, FA77R37, FA87R57, FA97R57, FA107R77, FA127R77, FA107R77, FA127R77, FA127R87, FA157R97
FFS37, FFS47, FFS57, FFS67, FFS77, FFS87, FFS97, FFS107, FFS127, FFS157
FF37R17, FF47R17, FF57R37, FF67R37, FF77R37, FF87R57, FF97R57, FF107R77, FF127R77, FF107R77, FF127R77, FF127R87, FF157R97
FAFS37, FAFS47, FAFS57, FAFS67, FAFS77, FAFS87, FAFS97, FAFS107, FAFS127, FAFS157
FAF37R17, FAF47R17, FAF57R37, FAF67R37, FAF77R37, FAF87R57, FAF97R57, FAF107R77, FAF127R77, FAF107R77, FAF127R77, FAF127R87, FAF157R97
FAZS37, FAZS47, FAZS57, FAZS67, FAZS77, FAZS87, FAZS97, FAZS107, FAZS127, FAZS157
FAZ37R17, FAZ47R17, FAZ57R37, FAZ67R37, FAZ77R37, FAZ87R57, FAZ97R57, FAZ107R77, FAZ127R77, FAZ107R77, FAZ127R77, FAZ127R87, FAZ157R97

Apart of type specification :

SIZE 37 47 57 67 77 87 97 107 127 157
DF DFA DFF DKAZ DFAF DFAZ
INPUT POWER RATING(KW) 0.18-0.30 0.18-3.0 0.18-5.5 0.18-5.5 0.37-11 0.75-22 1.1-30 2.2-45 7.5-90 11-260
RATIO 3.81-128.51 5.06-189.39 5.18-199.70 4.21-228.99 4.20-271.92 4.12-270.64 4.68-270.64 6.20-255.25 4.63-172.33 12.07-270.18
MAX TORQUE(N.m) 200 400 600 820 1500 3000 4300 7840 12000 18000
WEIGHT(KG) 13 18 34 55 90 150 260 402 700 950

Application :
Industrial Machine: Food Stuff, Ceramics, CHEMICAL, Packing, Dyeing,
Wood working, Glass.

Mounting position and Position of the motor terminal box :

750rpm-1500rpm Hollow Shaft Bevel Helical Speed Reducer Gearbox Reducer With Motor
750rpm-1500rpm Hollow Shaft Bevel Helical Speed Reducer Gearbox Reducer With Motor
750rpm-1500rpm Hollow Shaft Bevel Helical Speed Reducer Gearbox Reducer With Motor750rpm-1500rpm Hollow Shaft Bevel Helical Speed Reducer Gearbox Reducer With Motor
750rpm-1500rpm Hollow Shaft Bevel Helical Speed Reducer Gearbox Reducer With Motor

Why choose us :

750rpm-1500rpm Hollow Shaft Bevel Helical Speed Reducer Gearbox Reducer With Motor750rpm-1500rpm Hollow Shaft Bevel Helical Speed Reducer Gearbox Reducer With Motor750rpm-1500rpm Hollow Shaft Bevel Helical Speed Reducer Gearbox Reducer With Motor

F series process :
750rpm-1500rpm Hollow Shaft Bevel Helical Speed Reducer Gearbox Reducer With Motor
Packing and shipping way :
750rpm-1500rpm Hollow Shaft Bevel Helical Speed Reducer Gearbox Reducer With Motor
